9-376 VHF Circuit Board/Schematic Diagrams and Parts List (PCB 8415112H01)

R3505 0613952Q61 CER CHIP RES 330 OHM 5%

0402

R3506 0613952H15 CER CHIP RES 3.9 OHM 5%

0603

R3507 0613952H15 CER CHIP RES 3.9 OHM 5%

0603

R3512 NOT PLACED -

R3513 NOT PLACED -

R3519 0680539Z01 POWER METAL STRIP

RESISTORS

R3541 0613952R15 CER CHIP RES 39K OHM 5%

0402

R3542 0613952Q91 CER CHIP RES 5600 OHM 5%

0402

R3543 0613952Q49 CER CHIP RES 100 OHM 5%

0402

R3544 0613952H49 CER CHIP RES 100 OHM 5%

0603

R3545 0613952H49 CER CHIP RES 100 OHM 5%

0603

R3546 0613952R03 CER CHIP RES 12K OHM 5%

0402

R3547 0613952R13 CER CHIP RES 33K OHM 5%

0402

R3548 0613952R09 CER CHIP RES 22K OHM 5%

0402

R3551 0613952Q39 CER CHIP RES 39.0 OHM 5%

0402

R3561 0613952R03 CER CHIP RES 12K OHM 5%

0402

R3562 0613952R13 CER CHIP RES 33K OHM 5%

0402

R3563 0613952R35 CER CHIP RES 270K OHM

5% 0402

R3564 0613952R37 CER CHIP RES 330K OHM

5% 0402

R3565 NOT PLACED -

R3566 NOT PLACED -

R3569 0613952Q91 CER CHIP RES 5600 OHM 5%

0402

R3570 0613952R01 CER CHIP RES 10K OHM 5%

0402

R3571 0613952H51 CER CHIP RES 120 OHM 5%

0603

R3572 0613952H51 CER CHIP RES 120 OHM 5%

0603

R3573 0613952H51 CER CHIP RES 120 OHM 5%

0603

R3701 0613952Q49 CER CHIP RES 100 OHM 5%

0402

R3702 NOT PLACED -

R3703 0613952Q53 CER CHIP RES 150 OHM 5%

0402

R3704 0613952Q53 CER CHIP RES 150 OHM 5%

0402

R3705 0613952R13 CER CHIP RES 33K OHM 5%

0402

R3721 0613952Q65 CER CHIP RES 470 OHM 5%

0402

R3722 0613952Q67 CER CHIP RES 560 OHM 5%

0402

R3723 0613952Q49 CER CHIP RES 100 OHM 5%

0402

R3726 NOT PLACED -

R3727 0613952R25 CER CHIP RES 100K OHM

5% 0402

R3741 0613952Q49 CER CHIP RES 100 OHM 5%

0402

R3751 0613952R32 CER CHIP RES 200K OHM

5% 0402

R3752 0613952R31 CER CHIP RES 180K OHM

5% 0402

R3761 0613952R17 CER CHIP RES 47K OHM 5%

0402

R3762 NOT PLACED -

R3801 NOT PLACED -

R3802 0613952Q49 CER CHIP RES 100 OHM 5%

0402

R3803 0613952Q57 CER CHIP RES 220 OHM 5%

0402

R3804 0613952R01 CER CHIP RES 10K OHM 5%

0402

R3805 0613952R10 CER CHIP RES 24K OHM 5%

0402

R3806 0613952Q33 CER CHIP RES 22.0 OHM 5%

0402

R3807 NOT PLACED -

R3808 0613952Q25 CER CHIP RES 10.0 OHM 5%

0402

R3811 0613952Q49 CER CHIP RES 100 OHM 5%

0402

R3812 NOT PLACED -

R3816 0613952Q73 CER CHIP RES 1000 OHM 5%

0402

R3817 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R3818 NOT PLACED -

R3821 0613952Q57 CER CHIP RES 220 OHM 5%

0402

R3822 0613952Q41 CER CHIP RES 47.0 OHM 5%

0402

R3823 0613952R13 CER CHIP RES 33K OHM 5%

0402

R3824 0613952R09 CER CHIP RES 22K OHM 5%

0402

R3825 0613952Q37 CER CHIP RES 33.0 OHM 5%

0402

R3826 0613952Q31 CER CHIP RES 18.0 OHM 5%

0402

R3828 0613952Q49 CER CHIP RES 100 OHM 5%

0402

R3829 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R3830 NOT PLACED -

R3831 0613952R01 CER CHIP RES 10K OHM 5%

0402

R3832 0613952R03 CER CHIP RES 12K OHM 5%

0402

R3833 0613952Q57 CER CHIP RES 220 OHM 5%

0402

R3834 0613952Q41 CER CHIP RES 47.0 OHM 5%

0402

R3835 0613952R17 CER CHIP RES 47K OHM 5%

0402

R3836 0613952R01 CER CHIP RES 10K OHM 5%

0402

RT400 0680590Z01 THERMISTOR_33K

RT3301 NOT PLACED -

S501 4080710Z19 SWITCH, FREQUENCY

S502 1880619Z04 VOL POTENTIOMETER with

hi temp cam

SH400 2680505Z02 SHIELD, CONTROLLER TOP

LEFT

SH401 2680506Z02 SHIELD, CONTROLLER TOP

RIGHT

SH402 2680515Z02 SHIELD, CONTROLLER

BOTTOM LEFT

SH403 2680516Z02 SHIELD, CONTROLLER BTM

RIGHT

SH3202 2686539Z02 IF SECTION SHIELD

SH3203 2686527Z02 SHIELD, RFI/EMI, CRS, TIN

SH3301 2615144H01 SHIELD FOR GSM

PLACEMENT

SH3302 2615144H05 SHIELD FOR GSM

PLACEMENT

SH3303 2615144H06 SHIELD FOR GSM

PLACEMENT

SH3501 2615144H03 SHIELD FOR GSM

PLACEMENT

SH3502 2615144H04 SHIELD FOR GSM

PLACEMENT

SH3701 2680511Z02 SHIELD, SYNTHESIZER

SH3702 2680511Z02 SHIELD, SYNTHESIZER

SH3801 2680513Z02 SHIELD, VCO TOP

SH3802 2680514Z02 SHIELD, VCO BOTTOM/LVZIF

T3301 2515121H01 BALUN, TRANSFORMER

T3302 2515121H01 BALUN, TRANSFORMER

U303 5114005A01 IC LOW COST SING SPLY

LM2904DR

U400 5115012H01 IC,ADJ LOW

DROPOUT,SM,POS P

U404 5115062H01 IC,CUST,TQFP48

U405 5115020H01 IC,SRAM,32K X 8,SOIC,3.6V

U406 * 5115286H01 IC 4M FLASH ROM- NON

SHRINK+EPP

U407 * 5115033H01 IC,EEPROM,16K X 8,SM

U409 5185143E03 IC,MICROP,QFP,QFP100,3.7M

U410 5115044H01 IC,LOW DROPOUT,SM,3.3V

POS

U420 5115280H01 AUDIO AMPLIFIER

TDA8547TS

U602 5115014H01 IC,COMPTR,SM,SOT-23/5

U3201 5115019H01 IC,LOW DROPOUT,SOT-

23,SOT-23

U3220 5115281H01 FM IF IC SA616 FROM

PHILIPS

U3221 5115070H01 IC,INVTR,TC7W04FU,SSOP

U3501 5115678H01 VHF/UHF/800/900 MHZ

LDMOS DRIVER IC

U3502 5185765B26 IC PWR CTRL IN MOS20

U3503 5115022H01 IC,TEMP

SENS,LM50C,SM,SOT-23

U3701 5115060H01 IC,FREQ SYN,AT24701-OT4X

U3711 5115026H01 IC,LOW DROPOUT,SM,SOT-

23/6,P

U3801 5105750U56 IC PKG DIE VCO BUFFER

VR432 4813979P10 TRANS SUP 5.6V QUAD

VR433 4813979P10 TRANS SUP 5.6V QUAD

VR434 4815038H01 DIODE ARRAY,ZEN,SM,SOD-

323,6.93V

VR439 4813977M21 DIODE 12V ZENER _5242_

VR440 NOT PLACED -

VR441 NOT PLACED -

VR442 NOT PLACED -

VR444 NOT PLACED -

VR447 4813977A54 DIODE ZENER 0.2W SOD-323

10V

VR448 4813977A54 DIODE ZENER 0.2W SOD-323

10V

VR449 4813977A54 DIODE ZENER 0.2W SOD-323

10V

VR450 4815040H01 DIODE ARRAY

,ZEN,MM3Z12VT1G,SM,12

VR460 4815038H01 DIODE ARRAY,ZEN,SM,SOD-

323,6.93V,

VR501 4815038H01 DIODE ARRAY,ZEN,SM,SOD-

323,6.93V,

VR506 4815038H01 DIODE ARRAY,ZEN,SM,SOD-

323,6.93V,

VR3501 4813977M21 DIODE 12V ZENER _5242_

Y3200 9180022M11 XTAL FILTER 44.85MHZ

Y3201 4802245J84 XTAL 44.395MHz, 3RD OT,

SMD
