Motorola HT Series User Manual

9-388 VHF Circuit Board/Schematic Diagrams and Parts List
C430 2113928N01
0662057M01
0.1uF, 10%
0 (SUB on LS
+
Models Only)
C431 2113743N50 100pF
C433 2113743L41 0.01uF
C434 2113743M24 0.01uF
C435 2113743M24 0.01uF
C436 2113743N34 22pF
C437 2113743N34 22pF
C440 2113743G26 4.7uF
C441 2113743L09 470pF
C442 2113743E20 10 uF
C443 2113928N01 0.1uF
C444 2113743N50 100pF
C445 2113743L09 470pF
C446 2113743L09 470pF
C447 2113928N01 0.1uF
C448 2113928N01 0.1uF
C449 2113743N50 100pF
C451 2113743M08 0.022pF
C452 2113743G26 4.7uF
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF
C471 2113743L09 470pF
C472 2113743L09 470pF
C473 2113743L09 470pF
C474 2113743L41 0.01uF
C475 2113743H14 10uF
C476 2113928D08 10.0uF
C477 2113743L17 1000pF
C478 2113743L17 1000pF
C479 2113928N01 0.1uF
C480 2113928D08 10.0uF
C481 2113928N01 0.1uF
C482 2113928N01
0662057M01
0.1uF, 10%
0 (SUB on LS
+
Models Only)
C483 2113743L09 470pF
C484 2113743L09 470pF
C490 2113743L09 470pF
C491 2113743L09 470pF
C492 2113743L09 470pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743L09 470pF
C496 2113743L09 470pF
C497 2113743L09 470pF
C502 2311049A05 0.47uF
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
Circuit
Ref
Motorola Part
No.
Description
C514 2113743N50 100pF
C520 2113743L41 0.01uF
C521 2113743L41 0.01uF
C522 2113743L41 0.01uF
C523 2113743L41 0.01uF
C535 2113743L17 0.01uF
CR330 4802245J42 Ring Quad Diode
CR330 4805129M96 SMBV1032
CR330 4880154K03 Dual Common Anode Cathode
CR411 4802245J47 Schottky Diode
CR412 4802245J62 Schottky Diode
CR413 4802245J62 Schottky Diode
CR440 4813833C02 Dual Diode Common Cathode
CR501 4880107R01 Rectifier
CR503 4805729G49 LED Red/Yellow
D3270 4862824C01 Varactor
D3301 4802081B58 Dual Diode
D3302 4802081B58 Dual Diode
D3521 4880973Z02 Pin Diode
D3551 4880973Z02 Pin Diode
D3701 4802233J09 Triple Diode
D3702 4802233J09 Triple Diode
D3761 4862824C03 Varactor
D3821 4805649Q13 Dual Varactor
D3831 4805649Q13 Dual Varactor
D3832 4862824C01 Varactor
E400 2480640Z01 Ferrite Bead
E401 2480640Z01 Ferrite Bead
E402 2480640Z01 Ferrite Bead
E403 2480640Z01 Ferrite Bead
E404 2480640Z01 Ferrite Bead
E405 2480640Z01 Ferrite Bead
E406 2480640Z01 Ferrite Bead
E407 2480640Z01 Ferrite Bead
E408 2480640Z01 Ferrite Bead
E409 2480640Z01 Ferrite Bead
F501 6580542Z01 Fuse 3A
FL401 4870368G02 Crystal Oscillator 38.4 kHz
H3501 2680499Z01 Heatsink
J3501 0180117S05 RF Jack
J3502 0280519Z02 Antenna Nut
J400 0905505Y04 40-Pin Connector
J403 0905505Y02 20-Pin Connector
L3200 2462587N68 1uH
L3202 2462587N68 1uH
L3221 2462587N68 1uH
L3270 2462587T15 100nH
L3271 2462587Q20 2.2uH
L3301 2462587T35 12nH
L3303 2462587T35 12nH
L3304 2462587T23 470nH
L3305 2462587T35 12nH
L3306 2462587T35 12nH
L3308 2462587T34 10nH
L3309 2462587N55 150nH
L3312 2462587V28 33nH
Circuit
Ref
Motorola Part
No.
Description
L3501 2413926H09 5.6nH
L3503 2462587V32 68nH
L3504 2462587N51 68nH
L3511 2462587N44 18nH
L3512 2479990B01 11.03nH
L3513 2479990A02 7.66nH
L3515 2479990C03 13.85nH
L3518 2462587N48 39nH
L3519 2484657R01 Bead
L3521 2479990A02 7.66nH
L3522 2479990E01 23.75nH
L3523 2462587N68 1uH
L3531 2479990N01 43.67nH
L3532 2479990N01 43.67nH
L3538 2479990N01 30.54nH
L3551 2479990N01 43.67nH
L3552 2479990A02 7.66nH
L3701 2462587Q42 390nH
L3731 2462587Q20 2.2uH
L3801 2462587V34 100nH
L3809 2462587V27 27nH
L3811 2462587V34 100nH
L3812 2462587V34 100nH
L3813 2462587Q47 1uH
L3816 2462587V34 100nH
L3821 2462587N50 56nH
L3822 2462587N49 47nH
L3823 2462587N49 47nH
L3824 2462587N68 1uH
L3825 2462587V34 100nH
L3826 2462587N68 1uH
L3831 2462587N50 56nH
L3832 2462587N51 68nH
L3833 2462587N50 56nH
L3834 2462587N68 1uH
L400 2462587Q42 390nH
L401 2462587Q42 390uH
L410 2462587Q42 390uH
L411 2462587Q42 390uH
L505 2462587Q42 390uH
PB501 4080523Z01 Tactile, Pushbutton
PB502 4080523Z01 Tactile, Pushbutton
PB503 4080523Z01 Tactile, Pushbutton
PB504 4080523Z01 Tactile, Pushbutton
PB505 4080523Z01 Tactile, Pushbutton
Q3200 4813827A07 NPN
Q3201 4880214G02 NPN
Q3202 4880214G02 NPN
Q3270 4805218N63 BFQ67W
Q3301 4880214G02 NPN
Q3302 4813827A07 NPN
Q3501 4802245J55 RF Power FET
Q3561 4813824A17 PNP
Q3721 4802245J50 Dual NPN/PNP
Q3801 4813827A07 NPN
Q400 4809579E18 MOSFET P-Chan
Circuit
Ref
Motorola Part
No.
Description
Q403 4880214G02 NPN
Q405 4802245J54 Dual NPN
Q410 4802245J54 Dual NPN
Q416 4809579E18 MOSFET p-CHAN
Q417 4802245J50 Dual NPN/PNP
Q502 5180159R01 NPN
Q505 4880214G02 TSTR MMBT3904
R3200 0662057M54 150
R3201 0662057M82 2.2K
R3202 0662057M90 4.7K
R3203 0662057M98 10K 5
R3204 0662057M26 10
R3205 0662057M74 1K
R3206 0662057N23 100K
R3207 0662057N13 39K
R3208 0662057M50 100
R3209 0662057M74 1K
R3210 0662057M82 2.2K
R3211 0662057M82 2.2K
R3212 0662057M90 4.7K
R3213 0662057M82 2.2K
R3214 0662057M34 22
R3219 0662057M50 100
R3220 0662057M90 4.7K
R3221 0662057M50 100
R3224 0662057M26 10
R3225 0662057M74 1K
R3226 0662057M26 10
R3270 0662057M74 1KK
R3271 0662057M42 47 K
R3272 0662057N15 47KK
R3273 0662057N15 47K K
R3274 0662057M83 2.4K
R3275 0662057M74 1K
R3276 0662057N30 200K
R3303 0662057N23 100K
R3304 0662057N23 100K
R3305 0662057N19 68K
R3306 0662057M82 2.2K
R3307 0662057N11 33K
R3308 0662057M78 1.5K
R3309 0662057M92 5.6K
R3310 0662057M98 10K
R3311 0662057M26 10
R3312 0662057M38 33
R3313 0662057M34 22
R3314 0662057M26 10
R3315 0662057M62 330
R3316 0662057M66 470
R3317 0662057N23 100K
R3318 0662057M66 470
R3321 0662057M54 150
R3322 0662057M58 220
R3323 0662057M32 18
R3324 0662057M58 220
R3501 0662057M61 300
Circuit
Ref
Motorola Part
No.
Description

Motorola HT Series Specifications

General

Battery Type	Li-Ion
Waterproof	IP54
Operating Temperature	-30°C to +60°C
Frequency Range	VHF: 136-174 MHz
Number of Channels	16
