VHF Circuit Board/Schematic Diagrams and Parts List 9-389
* Motorola Depot Servicing only
R3502 0662057M32 18
R3503 0662057M61 300
R3505 0662057M62 330
R3512 0662057A27 120
R3513 0662057A25 100
R3519 0680539Z01 0.1
R3542 0662057M92 5.6K
R3543 0662057M50 100
R3544 0662057A25 100
R3545 0662057A25 100
R3546 0662057N11 33K
R3547 0662057N01 12K
R3548 0662057M95 7.5K
R3551 0662057M40 39
R3561 0662057N01 12K
R3562 0662057N11 33K
R3563 0662057N33 270K
R3564 0662057N35 330K
R3569 0662057M92 5600
R3570 0662057M98 10k
R3571 0662057A27 5.6K
R3572 0662057A27 120
R3573 0662057A27 120
R3701 0662057M50 100
R3703 0662057M54 150
R3704 0662057M54 150
R3705 0662057N11 33K
R3721 0662057M66 470
R3722 0662057M74 1000
R3723 0662057M50 100
R3727 0662057N23 100K
R3741 0662057M50 100
R3751 0662057N30 200K
R3752 0662057N35 330K
R3761 0662057N15 47K
R3802 0662057M50 100
R3803 0662057M58 220
R3804 0662057M98 10K
R3805 0662057N08 24K
R3806 0662057M34 22
R3808 0662057M26 10
R3811 0662057M50 100
R3816 0662057M74 1K
R3817 0662057M01 0
R3821 0662057M58 220
R3822 0662057M42 47
R3823 0662057N11 33K
R3824 0662057N07 22K
R3825 0662057M38 33
R3826 0662057M32 18
R3828 0662057M50 100
R3829 0662057M01 0
R3831 0662057M98 10K
R3832 0662057N01 12K
R3833 0662057M58 220
R3834 0662057M42 47
Circuit
Ref
Motorola Part
No.
Description
R3835 0662057N15 47K
R3836 0662057M98 10K
R400 0662057N15 47K
R401 0662057M01 0
R405 0662057M01 0
R406 0662057N20 75K
R407 0662057N19 68K
R409 0662057M98 10K
R410 0662057N23 100K
R411 0662057M98 10K
R413 0662057M01 0
R414 0662057V34 180K
R415 0662057V26 91K
R416 0662057N13 39K
R418 0662057M01 0
R419 0662057M67 0
R420 0662057B46 10M
R421 0662057M81 2K
R423 0662057N21 82K
R424 0662057N12 36K
R425 0662057N10 30K
R426 0662057N35 330K
R427 0662057M84 2700
R428 0662057M10 2.2
R429 0662057M98 10K
R431 0662057N39 470K
R432 0662057N16 51K
R434 0662057M62 330
R435 0662057M81 2K
R436 0662057M01 0
R445 0662057N08 24K
R446 0662057N31 220K
R447 0662057N51 1.5M
R448 0662057N33 270K
R449 0662057N08 24K
R450 0683962T45 68
R457 0662057M98 10K
R460 0662057M90 4.7K
R461 0662057M56 180
R462 0662057M98 10K
R463 0662057M61 300
R471 0662057M92 5.6K
R472 0662057M93 6.2K
R473 0662057M26 10
R475 0662057M01 0
R476 0662057N08 24K
R477 0662057M74 1K
R478 0662057M98 10K
R481 0662057N08 24K
R492 0662057M01 0
R501 0662057M70 680
R502 0662057M56 180
R505 0662057M98 10K
R506 0662057N15 47K
RT400 0680590Z01 33K
S501 4080710Z02 Frequency Switch
Circuit
Ref
Motorola Part
No.
Description
S502 1880619Z01 Volume Potentiometer
SH3201 2602023X08 Shield
SH3202 2686081B02 Shield
SH3203 2686081B03 Shield
SH3301 2686081B01 Shield
SH3302 2686081B05 Shield
SH3303 2686081B06 Shield
SH3501 2686081B03 Shield
SH3502 2686081B04 Shield
SH3701 2680511Z01 Shield, Synthesizer
SH3702 2680511Z01 Shield
SH3801 2680513Z01 Shield, VCO Top
SH3802 2680514Z01 Shield, VCO Bottom/LVZIF
SH400 2680505Z01 Controller Memory Shield
SH401 2680506Z01 Controller On/Off Shield
SH402 2680515Z01 Controller Microprocessor Shield
SH403 2680516Z01 Controller ASFIC Compander/
Audio PA Shield
T3301 2580541Z01 Transformer Coil
T3302 2580541Z01 Transformer Coil
U3201 5102463J58 3.3V Regulator
U3220 5109632D83 Low Voltage ZIF
U3501 5105109Z67 LDMOS Driver
U3502 5185765B01 Power Control IC
U3503 5185963A15 Temperature Sense
U3701 5185963A27 Low Voltage FracN
U3711 5105739X05 Regulator, Linear
U3801 5105750U54 VCO Buffer
U400 5102463J40 3.3V Regulator
U404 5185963A53 ASFIC
U405 5102463J36 Static RAM
U406 5102463J60 512KX8 Flash ROM
U407 5102463J64 16KX8 EEPROM
U409 5102226J56 Microcontroller
U410 5102463J57 3.3V Regulator
U420 5102463J44 Audio PA
VR432 4805656W08 5.6V Zener
VR433 4805656W08 5.6V Zener
VR434 4802245J51 6.8V Zener
VR439 4880140L15 10V Zener
VR447 4802245J53 10V Zener
VR448 4802245J53 10V Zener
VR449 4802245J53 10V Zener
VR450 4802245J53 10V Zener
VR501 4813830A18 6.8V Zener
VR506 4802245J51 6.8V Zener
Y3200 9186153B01 Crystal Filter
Y3761 4802245J49 Crystal 16.8 MHz
Circuit
Ref
Motorola Part
No.
Description
