800 MHz Circuit Board/Schematic Diagrams and Parts List (PCB 84860641Z02 / 8480641Z03 (Rev B) 9-425
C505 2113743N46 Capacitor Chip 68pF
C511 to C514 2113743N46 Capacitor Chip 68pF
C520 to C523 2113743L41 Capacitor Chip 0.01µF
C524 2113743N32 Capacitor Chip 18pF
C525 to C529 2113743N48 Capacitor Chip 82pF
C530 2311049A18 Capacitor Tantalum 10µF
C531 2113743N48 Capacitor Chip 82pF
CR101 to
CR102
4880973Z02 Diode PIN MA4PH261
CR203 4862824C03 Diode Varactor 1SV232
CR251 to
CR253
4862824C01 Diode Varactor 1SV229
CR300 4880154K03 Diode Schottky MMBD353LT1
CR301 4802245J41 Diode Switching HSMP3820
CR350 4862824C01 Diode Varactor 1SV229
CR411 to
CR413
4802245J62 Diode Array RB731U
CR440 4813833C02 Diode Dual Common Cathode
MMBD6100LT1
CR501 4880107R01 Diode Rectifier BYD17D
CR503 4805729G49 Opto-Device LED
BRPY1204W
D201 to D202 4802233J09 Diode Array IMN10
E101 9162002U03 Filter, EMI (for PCB No.
8480641Z02
Rev A only)
E101 2484657R01 2743019447 (for PCB No.
8480641Z03
Rev B only)
E102 2405688Z01 2744044446
E400 to E409 2480640Z01 BK1005HM471
F501 6580542Z01 Protector 1608FF
FL201 4802245J49 16.8 MHz Xtal Clip (not field
serviceable)
FL300 to
FL301
9180657Z01 Filter
FL350 4885631B01 Filter 31B01
FL401 4870368G02 Oscillator Crystal 68G02
J101 2880658Z02 Connector
J400 0905505Y04 Connector Multi_pin
FH12-40S-0.5SH
J403 0905505Y02 Connector Multi_pin CL586-
0524-9
L101 to L102 2460591A29 Inductor Airwound 6.61nH
L103 2460591A49 Inductor Airwound 8.01nH
L104 2462587V38 Inductor 220nH
L106 2479990B02 Inductor Airwound 19.61nH
L107 2413926G05 Inductor 6.8nH
L108 2413926G09 Inductor 15nH
L109 2462587V38 Inductor 220nH
L110 2413926G04 Inductor 5.6nH
L111 2413926G06 Inductor 8.2nH
L112 2479990A01 Inductor Airwound 4.22nH
L113 2462587V27 Inductor 27nH
L200 2462587Q20 Inductor 2.2µH
L202 2462587Q20 Inductor 2.2µH
Circuit
Ref
Motorola
Part No.
Description
L203 2462587V21 Inductor 6.8nH
L204 2462587P25 Inductor 12µH
L250 2462587V21 Inductor 6.8nH
L252 2462587V38 Inductor 220nH
L253 2462587V41 Inductor 390nH
L254 2462587V28 Inductor 33nH
L256 to L260 2462587V38 Inductor 220nH
L261 2462587V26 Inductor 22nH
L262 2462587V38 Inductor 220nH
L263 2462587V25 Inductor 18nH
L264 2462587V24 Inductor 15nH
L265 2462587V30 Inductor 47nH
L301 2462587V20 Inductor 3.3nH
L302 2462587V38 Inductor 220nH
L303 2462587V41 Inductor 390nH
L304 2413926G08 Inductor 12nH
L306 2462587V32 Inductor 68nH
L307 2462587V26 Inductor 22nH
L308 2462587V30 Inductor 47nH
L309 2462587V38 Inductor 220nH
L310 2462587V22 Inductor 8.2nH
L350 2462587Q20 Inductor 2.2µH
L351 to L352 2462587T22 Inductor 390nH
L353 2462587V35 Inductor 120nH
L354 2462587T23 Inductor 470nH
L355 2462587V38 Inductor 220nH
L356 2462587T40 Inductor 33nH
L357 2462587Q20 Inductor 2.2µH
L400 to L401 2462587Q42 Inductor 390nH
L410 to L411 2462587Q42 Inductor 390nH
L505 2462587Q42 Inductor 390nH
M100 7585651Z01 Mechanical (for PCB No.
8480641Z02
Rev A only)
M300 7585651Z01 Mechanical
(for PCB No. 8480641Z02
Rev A only)
M400 to M401 7585651Z01 Mechanical (for PCB No.
8480641Z02
Rev A only)
M501 to M502 7585651Z01 Mechanical (for PCB No.
8480641Z02
Rev A only)
PB501 to
PB505
4080523Z01 Mechanical KSS223G
Q101 5105385Y73 Transistor 85Y73
Q200 4802245J50 Transistor Bipolar
Q210 4802245J50 Transistor Bipolar
Q251 4805218N63 Transistor Bipolar BFQ67W
Q252 4802245J50 Transistor Bipolar
Q302 4802245J56 Transistor Bipolar QSBT0048
Q304 4802245J44 Transistor Bipolar HP415
Q350 4805218N63 Transistor Bipolar BFQ67W
Q400 4809579E18 Transistor FET TP0101T
Q403 4880214G02 Transistor Bipolar
MMBT3904L
Circuit
Ref
Motorola
Part No.
Description
Q405 4802245J54 Transistor Bipolar UMG5N
Q410 4802245J54 Transistor Bipolar UMG5N
Q416 4809579E18 Transistor FET TP0101T
Q417 4802245J50 Transistor Bipolar
Q502 5180159R01 Transistor Bipolar IMX1
Q505 4880214G02 Transistor Bipolar
MMBT3904L
R101 to R102 0662057A34 Resistor Chip 240
R103 0662057A18 Resistor Chip 51
R104 0680539Z01 Resistor Chip 0.1
R105 0662057M81 Resistor Chip 2K
R106 0662057M01 Resistor Chip 0
R107 0662057N13 Resistor Chip 39K
R108 0662057N08 Resistor Chip 24K
R109 0662057N20 Resistor Chip 75K
R110 0662057M47 Resistor Chip 75
R111 0680195M01 Resistor Chip 10
R112 0662057M01 Resistor Chip 0
R113 0662057N30 Resistor Chip 200K
R114 0662057M67 Resistor Chip 510
R115 0662057N39 Resistor Chip 470K
R116 0662057M85 Resistor Chip 3K
R117 0662057M98 Resistor Chip 10K
R200 0662057M50 Resistor Chip 100
R202 0662057M88 Resistor Chip 3.9K
R203 0662057M38 Resistor Chip 33
R204 0662057M52 Resistor Chip 120
R206 0662057N10 Resistor Chip 30K
R208 0662057N17 Resistor Chip 56K
R209 0662057M77 Resistor Chip 1.3K
R210 0662057M62 Resistor Chip 330
R211 0662057N15 Resistor Chip 47K
R213 0662057M50 Resistor Chip 100
R214 0662057N15 Resistor Chip 47K
R216 to R217 0662057M01 Resistor Chip 0
R218 0662057N11 Resistor Chip 33K
R219 to R220 0662057M54 Resistor Chip 150
R222 0662057M01 Resistor Chip 0
R250 0662057M60 Resistor Chip 270
R251 0662057M50 Resistor Chip 100
R253 0662057M26 Resistor Chip 10
R254 0662057N15 Resistor Chip 47K
R255 0662057M62 Resistor Chip 330
R256 0662057M01 Resistor Chip 0
R257 0662057M74 Resistor Chip 1K
R261 to R262 0662057M38 Resistor Chip 33
R263 to R264 0662057M60 Resistor Chip 270
R265 to R266 0662057N10 Resistor Chip 30K
R267 0662057N01 Resistor Chip 12K
R268 0662057N07 Resistor Chip 22K
R270 to R273 0662057M38 Resistor Chip 33
R274 0662057M52 Resistor Chip 120
R275 0662057M26 Resistor Chip 10
R306 0662057M92 Resistor Chip 5.6K
R307 0662057N17 Resistor Chip 56K
R309 0662057M70 Resistor Chip 680
Circuit
Ref
Motorola
Part No.
Description
R310 0662057N01 Resistor Chip 12K
R312 0662057M62 Resistor Chip 330
R315 0662057M74 Resistor Chip 1K
R317 0662057M96 Resistor Chip 8.2K
R318 0662057M72 Resistor Chip 820
R320 0662057M52 Resistor Chip 120
R321 0662057M43 Resistor Chip 51
R322 0662057M52 Resistor Chip 120
R323 0662057M87 Resistor Chip 3.6K
R324 0662057M68 Resistor Chip 560
R325 0662057N10 Resistor Chip 30K
R326 0662057M42 Resistor Chip 47
R327 0662057M40 Resistor Chip 39
R328 0662057N03 Resistor Chip 15K
R350 0662057M33 Resistor Chip 20
R351 0662057M52 Resistor Chip 120
R352 to R353 0662057N01 Resistor Chip 12K
R355 0662057M98 Resistor Chip 10K
R356 0662057M78 Resistor Chip 1.5K
R358 0662057N15 Resistor Chip 47K
R359 0662057M78 Resistor Chip 1.5K
R360 0662057N15 Resistor Chip 47K
R361 0662057M57 Resistor Chip 200
R362 0662057M98 Resistor Chip 10K
R363 0662057N15 Resistor Chip 47K
R364 0662057M81 Resistor Chip 2K
R365 0662057M87 Resistor Chip 3.6K
R366 0662057M78 Resistor Chip 1.5K
R400 0662057N15 Resistor Chip 47K
R401 0662057M01 Resistor Chip 0
R405 0662057M01 Resistor Chip 0
R406 0662057N20 Resistor Chip 75K
R407 0662057N19 Resistor Chip 68K
R409 0662057M98 Resistor Chip 10K
R410 0662057N23 Resistor Chip 100K
R411 0662057M98 Resistor Chip 10K
R413 0662057M01 Resistor Chip 0
R414 0662057V34 Resistor Chip 180K
R415 0662057V26 Resistor Chip 91K
R416 0662057M90 Resistor Chip 4.7K
R419 0662057M67 Resistor Chip 510
R420 0662057B46 Resistor Chip 10MEG
R421 0662057M81 Resistor Chip 2K
R423 0662057N39 Resistor Chip 470K
R424 0662057N12 Resistor Chip 36K
R425 0662057N10 Resistor Chip 30K
R426 0662057N35 Resistor Chip 330K
R427 0662057M84 Resistor Chip 2.7K
R428 0662057M10 Resistor Chip 2.2
R429 0662057M98 Resistor Chip 10K
R431 0662057N39 Resistor Chip 470K
R432 0662057N16 Resistor Chip 51K
R434 0662057M62 Resistor Chip 330
R435 0662057M81 Resistor Chip 2K
R436 0662057M74 Resistor Chip 1K
R437 0662057M01 Resistor Chip 0
Circuit
Ref
Motorola
Part No.
Description
