Motorola HT Series User Manual

9-426 800 MHz Circuit Board/Schematic Diagrams and Parts List (PCB 84860641Z02 / 8480641Z03 (Rev B)
* Motorola Depot Servicing only
R438 to R439 0662057M54 Resistor Chip 150
R445 0662057N08 Resistor Chip 24K
R446 0662057N22 Resistor Chip 91K
R447 0662057N38 Resistor Chip 430K
R448 0662057N06 Resistor Chip 20K
R449 0662057N08 Resistor Chip 24K
R450 0683962T45 Resistor Chip 68
R457 0662057M98 Resistor Chip 10K
R460 0662057M90 Resistor Chip 4.7K
R461 0662057M56 Resistor Chip 180
R462 0662057M98 Resistor Chip 10K
R463 0662057M61 Resistor Chip 300
R471 0662057M92 Resistor Chip 5.6K
R472 0662057N12 Resistor Chip 36K
R473 0662057M26 Resistor Chip 10
R475 0662057M01 Resistor Chip 0
R476 0662057N08 Resistor Chip 24K
R477 0662057M74 Resistor Chip 1K
R478 0662057M98 Resistor Chip 10K
R481 0662057N08 Resistor Chip 24K
R492 0662057M01 Resistor Chip 0
R501 0662057M70 Resistor Chip 680
R502 0662057M56 Resistor Chip 180
R505 0662057M98 Resistor Chip 10K
R506 0662057N15 Resistor Chip 47K
R507 0662057M01 Resistor Chip 0
RT400 0680590Z01 Resistor Thermal 33.0K
S501 4080710Z01 Mechanical Rotary Switch
S501 4080710Z02 Mechanical Rotary Switch
S502 1880619Z01 Mechanical
SH100 2680507Z01 Mechanical Shield 07Z01
SH101 2686081B04 Mechanical Shield 81B04
SH102 2680554Z01 Mechanical Shield 54Z01
SH201 2680511Z01 Mechanical Shield 11Z01
SH202 2680511Z01 Mechanical Shield 11Z01
SH250 2680514Z01 Mechanical Shield 14Z01
SH251 2680513Z01 Mechanical Shield 13Z01
SH301 2680554Z01 Mechanical Shield 54Z01
SH303 2680508Z01 Mechanical Shield 08Z01
SH350 2680508Z01 Mechanical Shield 08Z01
SH351 2680697Z01 Mechanical Shield 97Z01
SH352 2680553Z01 Mechanical Shield 53Z01
SH353 2680514Z01 Mechanical Shield 14Z01
SH400 2680505Z01 Mechanical Shield 05Z01
SH401 2680506Z01 Mechanical Shield 06Z01
SH402 2680515Z01 Mechanical Shield 15Z01
SH403 2680516Z01 Mechanical Shield 16Z01
U101 5102463J66 Analog IC Amp RF2103P
U102 5185765B28 Custom IC H99S-4
U103 5185963A15 Analog IC LM50CIM3X
U201 5185963A27 Custom IC ASIC 63A27
U205 4802245J58 Oscillator
DRR030KER900TCT
U206 4802245J57 Oscillator
DRR030KE1R225TC
U247 5105739X05 Analog IC ADP3300
Circuit
Ref
Motorola
Part No.
Description
U248 5102463J58 Analog IC Voltage Regulator
LP2980AIM5
U250 5105750U54 Custom IC Buffer/Driver
50U54
U301 5185963A43 Analog IC
MA4EX900L-1226
U302 5185623B01 Digital IC Gate
TC7SU04FTE85L
U350 5185623B01 Digital IC Gate
TC7SU04FTE85L
U351 5109632D83 Custom IC 32D83
U352 4885622B01 Transistor BF904
U400 5102463J40 Analog IC Voltage Regulator
LP2951ACMM-3.3
U404 5185963A53 Custom IC 63A53
U405 5102463J36 Digital IC Memory
U406 5102463J60 Digital IC Memory
AT49LV040-90T1
U407 5102463J64 Digital IC Memory
X25128-2.7
U409 5102226J56 Digital IC Microprocessor
MC68HC11FL0PU1
U410 5102463J57 Analog IC Voltage Regulator
ILC7062
U420 5102463J44 Analog IC Amp TDA8547TS
VR432 to
VR433
4805656W08 Diode MMQA5V6T1
VR434 4802245J73 Diode Zener UDZSTE17
VR445 to
VR449
4802245J74 Diode Zener UDZSTE17
VR450 4802245J75 Diode Zener UDZSTE17
VR501 4813830A18 Diode Zener MMBZ5235BLT1
VR502 4880140L17 Diode Zener MMBZ5242B
VR503 to
VR508
4802245J73 Diode Zener UDZSTE17
Y200 4802245J68 Oscillator Crystal TTS12V
B501 0986237A01 Connector Multi_Pin 37A01
B503 3980502Z01 Mechanical
B504 3980501Z01 Mechanical
C101 2113740F45 Capacitor Chip 56pF
C104 2113740F15 Capacitor Chip 3.3pF
C105 2113740F06 Capacitor Chip 1.3pF
C106 2113740F23 Capacitor Chip 6.8pF
C107 2113740F03 Capacitor Chip 1pF
C108 2113743N46 Capacitor Chip 68pF
C109 2113740F20 Capacitor Chip 5.1pF
C110 2113740F12 Capacitor Chip 2.4pF
Note:For optimum performance, diodes, transistors, integrated
circuits, and crystals must be ordered by Motorola part number
Circuit
Ref
Motorola
Part No.
Description
