Motorola HT Series User Manual

9-442 800 MHz Circuit Board/Schematic Diagrams and Parts List (PCB 8471827L03)
C369 2113946N03 CAPACITOR 2.2 UF
C370 2313960B57 CAPACITOR 10 UF
C371 2113946B04 CAPACITOR 0.10 UF
C372 2113945B05 CAPACITOR 0.033 UF
C373 2113946B04 CAPACITOR 0.10 UF
C374 2113946B04 CAPACITOR 0.10 UF
C375 2113945A14 CAPACITOR 4700 PF
C376 2113946B04 CAPACITOR 0.10 UF
C377 2113946B04 CAPACITOR 0.10 UF
C378 2113946B04 CAPACITOR 0.10 UF
C379 2113946B04 CAPACITOR 0.10 UF
C380 2113944A41 CAPACITOR 120 PF
C381 2113946B04 CAPACITOR 0.10 UF
C382 NOT PLACED NOT PLACED
C383 NOT PLACED NOT PLACED
C384 NOT PLACED NOT PLACED
C385 2113944A24 CAPACITOR 9.1 PF
C388 NOT PLACED NOT PLACED
C389 2113944A24 CAPACITOR 9.1 PF
C390 NOT PLACED NOT PLACED
C391 NOT PLACED NOT PLACED
C392 NOT PLACED NOT PLACED
C393 NOT PLACED NOT PLACED
C395 NOT PLACED NOT PLACED
C396 NOT PLACED NOT PLACED
C397 NOT PLACED NOT PLACED
C400 2113945B02 CAPACITOR 10000 PF
C401 2113946K02 CAPACITOR 0.10 UF
C402 2113946K02 CAPACITOR 0.10 UF
C403 2113955D33 CAPACITOR 2.2 UF
C404 2113944A36 CAPACITOR 68 PF
C405 2113944A36 CAPACITOR 68 PF
C406 NOT PLACED NOT PLACED
C407 2113946B04 CAPACITOR 0.10 UF
C408 2113944A36 CAPACITOR 68 PF
C409 2113946K02 CAPACITOR 0.10 UF
C410 2113946B04 CAPACITOR 0.10 UF
C411 2113946K02 CAPACITOR 0.10 UF
C412 2313960B57 CAPACITOR 10 UF
C414 2113946K02 CAPACITOR 0.10 UF
C415 2113944F13 CAPACITOR 0.01 UF
C416 2113946B04 CAPACITOR 0.10 UF
C419 NOT PLACED NOT PLACED
C420 2113945B02 CAPACITOR 10000 PF
C421 2113946B04 CAPACITOR 0.10 UF
C422 2113946K02 CAPACITOR 0.10 UF
C423 2113944A36 CAPACITOR 68 PF
C424 2313960B57 CAPACITOR 10 UF
C425 2113946K02 CAPACITOR 0.10 UF
C426 2113944A36 CAPACITOR 68 PF
C427 2113944A36 CAPACITOR 68 PF
Circuit
Ref
Motorola
Part No.
Description
C428 2113946K02 CAPACITOR 0.10 UF
C429 2113946K02 CAPACITOR 0.10 UF
C430 2113946B04 CAPACITOR 0.10 UF
C431 2113944A36 CAPACITOR 68 PF
C432 NOT PLACED NOT PLACED
C433 2113945B02 CAPACITOR 10000 PF
C434 2113946B04 CAPACITOR 0.10 UF
C435 2113946K02 CAPACITOR 0.10 UF
C436 2113944A29 CAPACITOR 22 PF
C437 2113944A29 CAPACITOR 22 PF
C438 2113946N03 CAPACITOR 2.2 UF
C439 2113946K02 CAPACITOR 0.10 UF
C440 2113946N03 CAPACITOR 2.2 UF
C441 2113944A36 CAPACITOR 68 PF
C442 2113945C31 CAPACITOR 0.1 UF
C443 2113946B04 CAPACITOR 0.10 UF
C444 2113944A36 CAPACITOR 68 PF
C445 2113944A36 CAPACITOR 68 PF
C447 2113945B04 CAPACITOR 0.022 UF
C448 2113946B04 CAPACITOR 0.10 UF
C449 2113944A36 CAPACITOR 68 PF
C450 NOT PLACED NOT PLACED
C451 2113945B04 CAPACITOR 0.022 UF
C452 2113955D31 CAPACITOR 1 UF
C453 2113944A36 CAPACITOR 68 PF
C456 2113944A36 CAPACITOR 68 PF
C458 2113944A36 CAPACITOR 68 PF
C459 2113944A36 CAPACITOR 68 PF
C463 2113944A36 CAPACITOR 68 PF
C466 2113944A36 CAPACITOR 68 PF
C467 2113946B04 CAPACITOR 0.10 UF
C471 2113944A36 CAPACITOR 68 PF
C472 2113944A36 CAPACITOR 68 PF
C473 2113944A36 CAPACITOR 68 PF
C475 2113956E91 CAPACITOR 10 UF
C476 2113946R01 CAPACITOR 10 UF
C479 2113946B04 CAPACITOR 0.10 UF
C480 2113946R01 CAPACITOR 10 UF
C481 2113946B04 CAPACITOR 0.10 UF
C482 2113946B04 CAPACITOR 0.10 UF
C490 2113944A36 CAPACITOR 68 PF
C491 2113944A36 CAPACITOR 68 PF
C492 2113944A36 CAPACITOR 68 PF
C493 2113944A36 CAPACITOR 68 PF
C494 2113944A36 CAPACITOR 68 PF
C495 2113944A36 CAPACITOR 68 PF
C496 2113944A36 CAPACITOR 68 PF
C497 2113944A36 CAPACITOR 68 PF
C498 2113946K02 CAPACITOR 0.10 UF
C502 2313960A55 CAPACITOR 0.47 UF
C503 2113944A36 CAPACITOR 68 PF
Circuit
Ref
Motorola
Part No.
Description
C505 2113944A36 CAPACITOR 68 PF
C511 2113944A36 CAPACITOR 68 PF
C512 2113944A36 CAPACITOR 68 PF
C513 2113944A36 CAPACITOR 68 PF
C514 2113944A36 CAPACITOR 68 PF
C520 2113945B02 CAPACITOR 10000 PF
C521 2113945B02 CAPACITOR 10000 PF
C522 2113945B02 CAPACITOR 10000 PF
C523 2113945B02 CAPACITOR 10000 PF
C524 2113944A28 CAPACITOR 18 PF
C525 2113944A38 CAPACITOR 82 PF
C526 2113944A38 CAPACITOR 82 PF
C527 2113944A38 CAPACITOR 82 PF
C528 2113944A38 CAPACITOR 82 PF
C529 2113944A38 CAPACITOR 82 PF
C530 2113944A40 CAPACITOR 100 PF
C531 2113944A38 CAPACITOR 82 PF
C532 2113944A40 CAPACITOR 100 PF
C533 2113944A40 CAPACITOR 100 PF
C534 2113944A40 CAPACITOR 100 PF
C535 2113944A40 CAPACITOR 100 PF
C536 2113944A40 CAPACITOR 100 PF
C537 2313960F04 CAPACITOR 33 UF
CR101 4880973Z02 PIN DIODE
CR102 4880973Z02 PIN DIODE
CR203 4815072H01 DIODE VARACTOR 1SV232
CR251 4885055Y01 DIODE VARACTOR 15V
CR252 4885055Y01 DIODE VARACTOR 15V
CR253 4885055Y01 DIODE VARACTOR 15V
CR300 4815048H01 DIODE DUAL MMBD353
CR411 4815067H01 DIODE RB731UFT108
CR412 4815067H01 DIODE RB731UFT108
CR413 4815067H01 DIODE RB731UFT108
CR440 4813978C02 DIODE SWITCHING
CR501 4815155H01 DIODE GL34D/32-LF
CR503 4805729G49 DIODE RED/YELLOW
D201 4815011H01 DIODE SWITCHING TRIPLE
D202 4815011H01 DIODE SWITCHING TRIPLE
D350 4815048H01 DIODE DUAL MMBD353
E101 2415954H02 INDUCTOR BEAD CHIP
E102 2405688Z01 INDUCTOR FERRITE BEAD
E400 2480640Z01 FERRITE BEAD
E401 2480640Z01 FERRITE BEAD
E402 2480640Z01 FERRITE BEAD
E403 2480640Z01 FERRITE BEAD
E404 2480640Z01 FERRITE BEAD
E405 2480640Z01 FERRITE BEAD
E406 2480640Z01 FERRITE BEAD
E407 2480640Z01 FERRITE BEAD
E408 2480640Z01 FERRITE BEAD
E409 2480640Z01 FERRITE BEAD
Circuit
Ref
Motorola
Part No.
Description
F501 6515076H01 FUSE CHIP TR/1608FF 3A
FL201 4805875Z04 CRYSTAL 16.8 MHZ
FL300 9180657Z01 FLTR RX 3-POLE CERAMIC
FL301 9180657Z01 FLTR RX 3-POLE CERAMIC
FL350 9116854H01
FLTR 73.35 MHZ 4
ELEMENT
FL351 9116854H01
FLTR 73.35 MHZ 4
ELEMENT
FL352 9115811H04
FLTR SMD455KHZ 6
ELEMENT
FL353 9180468V06
FLTR SMD455KHZ 4
ELEMENT
FL401 4870368G02 RESONATOR 38.4KHZ
J101 2880658Z06 CONN RF
J400 0915064H03 CONN ZIF 40 PINS
J403 0915064H02 CONN ZIF 20 PINS
L101 2460591A29 INDUCTOR 6.61 NH
L102 2460591A29 INDUCTOR 6.61 NH
L103 2460591A49 INDUCTOR 8.01 NH
L104 2414032F38 INDUCTOR 220 NH
L106 2479990B02 INDUCTOR 19.61 NH
L107 2414017G19 INDUCTOR 100 NH
L108 2414017G18 INDUCTOR 82 NH
L110 2414017G05 INDUCTOR 6.8 NH
L113 2414032F27 INDUCTOR 27 NH
L120 2414017G12 INDUCTOR 27 NH
L121 2415428H03 INDUCTOR 3.85 UH
L122 2414017G18 INDUCTOR 82 NH
L200 2414017Q20 INDUCTOR 2.2 UH
L202 2414017Q20 INDUCTOR 2.2 UH
L203 2414032F21 INDUCTOR 6.8 NH
L204 2414032L25 INDUCTOR 12 UH
L250 2414032F21 INDUCTOR 6.8 NH
L252 2414032F38 INDUCTOR 220 NH
L253 2414032F41 INDUCTOR 390 NH
L254 2414032F28 INDUCTOR 33 NH
L256 2414032F38 INDUCTOR 220 NH
L257 2414032F38 INDUCTOR 220 NH
L258 2414032F38 INDUCTOR 220 NH
L259 2414032F38 INDUCTOR 220 NH
L260 2414032F38 INDUCTOR 220 NH
L261 2414032F26 INDUCTOR 22 NH
L262 2414032F38 INDUCTOR 220 NH
L263 2414032F25 INDUCTOR 18 NH
L264 2414032F24 INDUCTOR 15 NH
L265 2414032F30 INDUCTOR 47 NH
L301 2414017N10 INDUCTOR 6.8 NH
L302 2414017N13 INDUCTOR 12 NH
L303 2415429H47 INDUCTOR 390 NH
L304 2414017G10 INDUCTOR 18 NH
L306 2414032B55 INDUCTOR 150 NH
Circuit
Ref
Motorola
Part No.
Description
