800 MHz Circuit Board/Schematic Diagrams and Parts List (PCB 8471827L03) 9-443
L307 2415429H21 INDUCTOR 22 NH
L308 2415429H30 INDUCTOR 47 NH
L309 2415429H43 INDUCTOR 220 NH
L310 2414032F57 INDUCTOR 4.7NH
L311 2414017N10 INDUCTOR 6.8 NH
L312 0613952R66 RESISTOR 0 OHM
L313 2414017N06 INDUCTOR 3.3 NH
L350 NOT PLACED NOT PLACED
L351 2414017K29 INDUCTOR 330 NH
L352 2414017K29 INDUCTOR 330 NH
L353 2414017K30 INDUCTOR 390 NH
L354 2414015A13 INDUCTOR 560 NH
L355 NOT PLACED NOT PLACED
L400 2414017Q42 INDUCTOR 390 NH
L401 2414017Q42 INDUCTOR 390 NH
L410 2414017Q42 INDUCTOR 390 NH
L411 2414017Q42 INDUCTOR 390 NH
L505 2414017Q42 INDUCTOR 390 NH
M101 3916333H01 GROUND CONTACT
PB501 4086470Z01 TACTILE SWITCH
PB502 4086470Z01 TACTILE SWITCH
PB503 4086470Z01 TACTILE SWITCH
PB504 4086470Z01 TACTILE SWITCH
PB505 4086470Z01 TACTILE SWITCH
Q101 4816698H01 TSTR RD05MMP1-T112
Q200 4815055H01 TSTR UMC5NT2
Q210 4815055H01 TSTR UMC5NT2
Q251 4805218N63 TSTR BFQ67W
Q252 4815055H01 TSTR UMC5NT2
Q301 4815267H01 TSTR SOT-363/SC-88
Q302 4802247J01 TSTR BFS505
Q304 4816531H01 TSTR QSBT-0038-TRIG
Q350 4802197J95 TSTR PBR941
Q351 4802197J95 TSTR PBR941
Q352 4813973M07 TSTR T3906
Q400 4815069H02 TSTR MOSFET
Q403 4813973A13 TSTR T3906
Q405 4815066H01 TSTR UMG5NFTR
Q410 4815066H01 TSTR UMG5NFTR
Q411 NOT PLACED NOT PLACED
Q416 4815069H02 TSTR MOSFET
Q417 4815055H01 TSTR UMC5NT2
Q502 4815154H01 TSTR DUAL SMT6
Q505 4813973M07 TSTR T3906
R101 0613952H58 RESISTOR 240 OHM
R102 0613952H58 RESISTOR 240 OHM
R103 0613952H42 RESISTOR 51 OHM
R104 0615043C01 RESISTOR METAL STRIP
R105 0613952Q80 RESISTOR 2000 OHM
R106 0613952R66 RESISTOR 0 OHM
R107 0613952R15 RESISTOR 39K OHM
Circuit
Ref
Motorola
Part No.
Description
R108 0613952R10 RESISTOR 24K OHM
R109 0613952R15 RESISTOR 39K OHM
R113 0613952R32 RESISTOR 200K OHM
R114 0613952R66 RESISTOR 0 OHM
R115 0613952R41 RESISTOR 470K OHM
R116 0613952Q84 RESISTOR 3000 OHM
R117 0613952R01 RESISTOR 10K OHM
R120 0613952Q53 RESISTOR 150 OHM
R121 0613952Z22 RESISTOR 220 OHM
R122 0613952H73 RESISTOR 1000 OHM
R123 NOT PLACED NOT PLACED
R124 NOT PLACED NOT PLACED
R200 0613952Q49 RESISTOR 100 OHM
R202 0613952Q87 RESISTOR 3900 OHM
R203 0613952Q37 RESISTOR 33 OHM
R204 0613952Q51 RESISTOR 120 OHM
R206 0613952R12 RESISTOR 30K OHM
R208 0613952R19 RESISTOR 56K OHM
R209 0613952Q76 RESISTOR 1300 OHM
R210 0613952Q61 RESISTOR 330 OHM
R211 0613952R17 RESISTOR 47K OHM
R212 NOT PLACED NOT PLACED
R213 0613952Q49 RESISTOR 100 OHM
R214 0613952R17 RESISTOR 47K OHM
R216 0613952R66 RESISTOR 0 OHM
R217 0613952R66 RESISTOR 0 OHM
R218 0613952R13 RESISTOR 33K OHM
R219 0613952Q53 RESISTOR 150 OHM
R220 0613952Q53 RESISTOR 150 OHM
R221 NOT PLACED NOT PLACED
R222 0613952R66 RESISTOR 0 OHM
R223 NOT PLACED NOT PLACED
R250 0613952Q59 RESISTOR 270 OHM
R251 0613952Q49 RESISTOR 100 OHM
R253 0613952Q25 RESISTOR 10 OHM
R254 0613952R17 RESISTOR 47K OHM
R255 0613952Q61 RESISTOR 330 OHM
R256 0613952R66 RESISTOR 0 OHM
R257 0613952Q73 RESISTOR 1000 OHM
R261 0613952Q37 RESISTOR 33 OHM
R262 0613952Q37 RESISTOR 33 OHM
R263 0613952Q53 RESISTOR 150 OHM
R264 0613952Q59 RESISTOR 270 OHM
R265 0613952R12 RESISTOR 30K OHM
R266 0613952R18 RESISTOR 51K OHM
R267 0613952R03 RESISTOR 12K OHM
R268 0613952R09 RESISTOR 22K OHM
R269 NOT PLACED NOT PLACED
R270 0613952Q37 RESISTOR 33 OHM
R271 0613952Q37 RESISTOR 33 OHM
R272 0613952Q37 RESISTOR 33 OHM
Circuit
Ref
Motorola
Part No.
Description
R273 0613952Q37 RESISTOR 33 OHM
R274 0613952Q51 RESISTOR 120 OHM
R275 0613952Q25 RESISTOR 10 OHM
R306 0613952Q91 RESISTOR 5600 OHM
R307 0613952R11 RESISTOR 27K OHM
R309 2113944A36 CAPACITOR 68 PF
R310 0613952Q91 RESISTOR 5600 OHM
R311 NOT PLACED NOT PLACED
R312 0613952Q45 RESISTOR 68 OHM
R314 0613952Q91 RESISTOR 5600 OHM
R316 NOT PLACED NOT PLACED
R317 NOT PLACED NOT PLACED
R318 NOT PLACED NOT PLACED
R319 NOT PLACED NOT PLACED
R320 0613952Q42 RESISTOR 51 OHM
R323 0613952R66 RESISTOR 0 OHM
R324 0613952Q67 RESISTOR 560 OHM
R325 0613952R12 RESISTOR 30K OHM
R326 0613952Q41 RESISTOR 47 OHM
R327 0613952Q39 RESISTOR 39 OHM
R328 0613952R05 RESISTOR 15K OHM
R329 0613952R66 RESISTOR 0 OHM
R330 NOT PLACED NOT PLACED
R331 NOT PLACED NOT PLACED
R334 NOT PLACED NOT PLACED
R335 NOT PLACED NOT PLACED
R350 0613952R03 RESISTOR 12K OHM
R351 0613952Q25 RESISTOR 10 OHM
R352 0613952Q93 RESISTOR 6800 OHM
R353 0613952R02 RESISTOR 11K OHM
R354 0613952Q68 RESISTOR 620 OHM
R355 0613952Q49 RESISTOR 100 OHM
R356 0613952R03 RESISTOR 12K OHM
R357 0613952R66 RESISTOR 0 OHM
R358 0613952Q93 RESISTOR 6800 OHM
R359 0613952R02 RESISTOR 11K OHM
R360 0613952Q61 RESISTOR 330 OHM
R361 0613952Q63 RESISTOR 390 OHM
R362 0613952Q61 RESISTOR 330 OHM
R363 0613952Q42 RESISTOR 51 OHM
R364 0613952Q71 RESISTOR 820 OHM
R365 NOT PLACED NOT PLACED
R366 0613952Q79 RESISTOR 1800 OHM
R367 0613952R03 RESISTOR 12K OHM
R368 0613952R01 RESISTOR 10K OHM
R369 0613952Q69 RESISTOR 680 OHM
R370 0613952R03 RESISTOR 12K OHM
R371 0613952Q79 RESISTOR 1800 OHM
R372 0613952Q63 RESISTOR 390 OHM
R373 0613952Q75 RESISTOR 1200 OHM
R374 0613952Q85 RESISTOR 3300 OHM
Circuit
Ref
Motorola
Part No.
Description
R375 0613952Q82 RESISTOR 2400 OHM
R376 0613952R66 RESISTOR 0 OHM
R377 NOT PLACED NOT PLACED
R379 NOT PLACED NOT PLACED
R400 0613952R17 RESISTOR 47K OHM
R401 0613952R66 RESISTOR 0 OHM
R402 NOT PLACED NOT PLACED
R403 NOT PLACED NOT PLACED
R405 0613952R66 RESISTOR 0 OHM
R406 0613952R22 RESISTOR 75K OHM
R407 0613952R21 RESISTOR 68K OHM
R408 NOT PLACED NOT PLACED
R409 0613952R01 RESISTOR 10K OHM
R410 0613952R25 RESISTOR 100K OHM
R411 0613952R01 RESISTOR 10K OHM
R413 0613952R66 RESISTOR 0 OHM
R414 0613952Z75 RESISTOR 180K OHM
R415 0613952Z72 RESISTOR 910K OHM
R416 0613952R01 RESISTOR 10K OHM
R418 NOT PLACED NOT PLACED
R419 0613952Q66 RESISTOR 510 OHM
R420 0613952J73 RESISTOR 10M OHM
R421 0613952Q80 RESISTOR 2000 OHM
R423 0613952R41 RESISTOR 470K OHM
R424 0613952R14 RESISTOR 36K OHM
R425 0613952R12 RESISTOR 30K OHM
R426 0613952R37 RESISTOR 330K OHM
R427 0613952Q83 RESISTOR 2700 OHM
R428 0613952Q09 RESISTOR 2.2 OHM
R429 0613952R22 RESISTOR 75K OHM
R431 0613952R41 RESISTOR 470K OHM
R432 0613952R18 RESISTOR 51K OHM
R434 0613952Q61 RESISTOR 330 OHM
R435 0613952Q80 RESISTOR 2000 OHM
R436 0613952Q73 RESISTOR 1000 OHM
R436 0613952R66 RESISTOR 0 OHM
R437 0613952R66 RESISTOR 0 OHM
R438 0613952R66 RESISTOR 0 OHM
R439 0613952Q53 RESISTOR 150 OHM
R445 0613952R10 RESISTOR 24K OHM
R447 0613952R25 RESISTOR 100K OHM
R448 0613952R01 RESISTOR 10K OHM
R449 0613952R10 RESISTOR 24K OHM
R450 0613959Y45 RESISTOR 68 OHM
R451 0613952R05 RESISTOR 15K OHM
R452 0613952R25 RESISTOR 100K OHM
R453 NOT PLACED NOT PLACED
R454 NOT PLACED NOT PLACED
R455 NOT PLACED NOT PLACED
R456 0613952R66 RESISTOR 0 OHM
R457 0613952R01 RESISTOR 10K OHM
Circuit
Ref
Motorola
Part No.
Description
