9-462 900 MHz Circuit Board/Schematic Diagrams and Parts List (PCB 8485910Z01)
900 MHz Radio Parts List for PMUF1059A, and
PMUF1060A
Circuit
Ref
Motorola Part
No.
Description
B501 0986237A02 Battery Contact Module
B503 3980502Z01 Backup battery B+
B504 3980501Z01 Backup battery B-
CAPACITOR, FIXED
C101 2113743N42 Capacitor Chip 47pF
C102 2113743N44 Capacitor Chip 56pF
C103 2113743N30 Capacitor Chip 15pF
C104 2113743N48 Capacitor Chip 82pF
C105 2113743N44 Capacitor Chip 56pF
C106 to
C107
2113743N30 Capacitor Chip 15pF
C108 2113743N44 Capacitor Chip 56pF
C109 2113743N30 Capacitor Chip 15pF
C110 2113743N42 Capacitor Chip 47pF
C111 2113743N44 Capacitor Chip 56pF
C112 2113743N30 Capacitor Chip 15pF
C113 2113740F01 Capacitor Chip 0.5pF
C114 2113740F16 Capacitor Chip 3.6pF
C115 2113740F18 Capacitor Chip 4.3pF
C116 2113743L29 Capacitor Chip 3300pF
C117 2311049A08 Capacitor Tantalum 1µF
C118 2113743N30 Capacitor Chip 15pF
C119 2113743N44 Capacitor Chip 56pF
C120 to
C121
2113740F45 Capacitor Chip 56pF
C122 2113743N30 Capacitor Chip 15pF
C123 2113743N44 Capacitor Chip 56pF
C124 2113740F09 Capacitor Chip 1.8pF
C125 2113740F15 Capacitor Chip 3.3pF
C126 2113740F09 Capacitor Chip 1.8pF
C127 2103689A19 Capacitor Chip 6.0pF
C128 2113743N42 Capacitor Chip 47pF
C130 to
C131
2113743M24 Capacitor Chip 0.1µF
C132 2113743N44 Capacitor Chip 56pF
C133 2113743N30 Capacitor Chip 15pF
C134 2113743N42 Capacitor Chip 47pF
C135 2113743N10 Capacitor Chip 2.2µF
C136 2113743M08 Capacitor Chip 0.022µF
C137 2113743N44 Capacitor Chip 56pF
C138 2113740F03 Capacitor Chip 1pF
C139 2113743M24 Capacitor Chip 0.1µF
C140 2113743N32 Capacitor Chip 18pF
C141 2113743N50 Capacitor Chip 100pF
C142 2103689A45 Capacitor Chip 20pF
C144 2113743N44 Capacitor Chip 56pF
C145 2113743M08 Capacitor Chip 0.022µF
C146 2113743N44 Capacitor Chip 56pF
C147 2113743M24 Capacitor Chip 0.1µF
C148 2113743M08 Capacitor Chip 0.022µF
C149 2113743N25 Capacitor Chip 9.1pF
C150 to
C152
2113743N42 Capacitor Chip 47pF
C153 2113743N44 Capacitor Chip 56pF
C154 to
C155
2113743N42 Capacitor Chip 47pF
C156 2113743L13 Capacitor Chip 680pF
C157 2113743L13 Capacitor Chip 680pF
C158 2113743L41 Capacitor Chip 0.01µF
C159 to
C161
2113743N42 Capacitor Chip 47pF
C162 2113743M24 Capacitor Chip 0.1µF
C163 2103689A47 Capacitor Chip 24pF
C164 2113743N26 Capacitor Chip 10pF
C165 2113743M24 Capacitor Chip 0.1µF
C200 2113743F18 Capacitor Chip 2.2µF
C201 2113743N44 Capacitor Chip 56pF
C202 2113743F18 Capacitor Chip 2.2µF
C203 2311049A57 Capacitor Tantalum 10µF
C204 to
C206
2113743M24 Capacitor Chip 0.1µF
C207 2113743F18 Capacitor Chip 2.2µF
C208 2113743M24 Capacitor Chip 0.1µF
C209 2311049A57 Capacitor Tantalum 10µF
C210 2113743N42 Capacitor Chip 47pF
C211 2311049A09 Capacitor Tantalum 2.2µF
C212 to
C213
2113743M24 Capacitor Chip 0.1µF
C214 2113743F18 Capacitor Chip 2.2µF
C215 2113743M24 Capacitor Chip 0.1µF
C216 2113743N42 Capacitor Chip 47pF
C217 2113743F18 Capacitor Chip 2.2µF
C218 2109720D14 Capacitor Chip 0.1µF
C219 to
C224
2113743N42 Capacitor Chip 47pF
C225 2113743E12 Capacitor Chip 0.047µF
C226 2113743E13 Capacitor Chip 0.068µF
C227 2113743N44 Capacitor Chip 56pF
C228 2113743N05 Capacitor Chip 1.2pF
C229 2113743F18 Capacitor Chip 2.2µF
C230 2113743N42 Capacitor Chip 47pF
C231 2113741F17 Capacitor Chip 470pF
C232 2113743N42 Capacitor Chip 47pF
C233 2113743M24 Capacitor Chip 0.1µF
C234 2311049A59 Capacitor Tantalum 10µF
C235 2113743N44 Capacitor Chip 56pF
C236 2113743N08 Capacitor Chip 1.6pF
C237 2113740F63 Capacitor Chip 330pF
C238 2113743M24 Capacitor Chip 0.1µF
C239 2113743L41 Capacitor Chip 0.01µF
C240 2113743N42 Capacitor Chip 47pF
C241 2113743N44 Capacitor Chip 56pF
C242 2113743N42 Capacitor Chip 47pF
C243 2113743N34 Capacitor Chip 22pF
C244 to
C247
2113743L41 Capacitor Chip 0.01µF
C249 2113743N42 Capacitor Chip 47pF
C250 2113743M24 Capacitor Chip 0.1µF
C251 2113743N44 Capacitor Chip 56pF
C252 2113743M24 Capacitor Chip 0.1µF
Circuit
Ref
Motorola Part
No.
Description
C253 2113743N46 Capacitor Chip 68pF
C254 2113743N44 Capacitor Chip 56pF
C255 2113743N01 Capacitor Chip 0.5pF
C256 2113743N22 Capacitor Chip 6.8pF
C257 2113743N44 Capacitor Chip 56pF
C258 2113743M24 Capacitor Chip 0.1µF
C259 2113743F18 Capacitor Chip 2.2µF
C260 2113743N44 Capacitor Chip 56pF
C261 2113743N46 Capacitor Chip 68pF
C262 2113743M24 Capacitor Chip 0.1µF
C263 2113743N44 Capacitor Chip 56pF
C264 2113743M24 Capacitor Chip 0.1µF
C265 to
C267
2113743N09 Capacitor Chip 2pF
C268 2113743N03 Capacitor Chip 1pF
C269 2113743M12 Capacitor Chip 0.033µF
C270 2113743M24 Capacitor Chip 0.1µF
C271 2113743N20 Capacitor Chip 5.6pF
C272 2113743N01 Capacitor Chip 0.5pF
C273 2113743N13 Capacitor Chip 3pF
C274 2113743N44 Capacitor Chip 56pF
C275 2113743N02 Capacitor Chip 0.75pF
C276 2113743N17 Capacitor Chip 4.3pF
C277 2113743N15 Capacitor Chip 3.6pF
C278 2113743N13 Capacitor Chip 3pF
C279 2113743N12 Capacitor Chip 2.7pF
C280 2113743M24 Capacitor Chip 0.1µF
C281 2113743N44 Capacitor Chip 56pF
C282 2113743N46 Capacitor Chip 68pF
C283 2113743N03 Capacitor Chip 1pF
C284 2113743N42 Capacitor Chip 47pF
C285 2113743M24 Capacitor Chip 0.1µF
C286 2113743N44 Capacitor Chip 56pF
C287 2113743N50 Capacitor Chip 100pF
C289 2113743M12 Capacitor Chip 0.033µF
C290 2113743N42 Capacitor Chip 47pF
C291 to
C292
2113743N44 Capacitor Chip 56pF
C293 2113743M24 Capacitor Chip 0.1µF
C294 2113743N44 Capacitor Chip 56pF
C295 2113743N46 Capacitor Chip 68pF
C300 2113743N24 Capacitor Chip 8.2pF
C301 2113743N44 Capacitor Chip 56pF
C302 2113743M24 Capacitor Chip 0.1µF
C303 2113743N42 Capacitor Chip 47pF
C304 2113743M24 Capacitor Chip 0.1µF
C305 2113743N42 Capacitor Chip 47pF
C306 to
C307
2113743N44 Capacitor Chip 56pF
C308 2113743N03 Capacitor Chip 1pF
C309 2113743N46 Capacitor Chip 68pF
C310 2113743N30 Capacitor Chip 15pF
C311 2113743N46 Capacitor Chip 68pF
C312 2113743N37 Capacitor Chip 30pF
C313 to
C314
2113743N46 Capacitor Chip 68pF
Circuit
Ref
Motorola Part
No.
Description
C315 2113743N19 Capacitor Chip 5.1pF
C316 to
C317
2113743N42 Capacitor Chip 47pF
C318 2113743N44 Capacitor Chip 56pF
C319 2113743N46 Capacitor Chip 68pF
C320 2113743M24 Capacitor Chip 0.1µF
C321 2113743N14 Capacitor Chip 3.3pF
C350 2311049A59 Capacitor Tantalum 10µF
C352 2113743M08 Capacitor Chip 0.022µF
C353 2113743A23 Capacitor Chip 0.22µF
C354 2113743M08 Capacitor Chip 0.022µF
C355 2113743E20 Capacitor Chip 0.1µF
C356 2113743N50 Capacitor Chip 100pF
C357 2113743F16 Capacitor Chip 1µF
C358 2113743M24 Capacitor Chip 0.1µF
C359 to
C360
2113743A23 Capacitor Chip 0.22µF
C361 to
C362
2113743R33 Capacitor Chip 4700pF
C363 to
C364
2113743F16 Capacitor Chip 1µF
C365 2113743N65 Capacitor Chip 8pF
C366 2113743F16 Capacitor Chip 1µF
C367 2113743M08 Capacitor Chip 0.022µF
C369 2113743R33 Capacitor Chip 4700pF
C370 2113743M24 Capacitor Chip 0.1µF
C371 2113743R33 Capacitor Chip 4700pF
C372 2113743A23 Capacitor Chip 0.22µF
C373 2311049A59 Capacitor Tantalum 10µF
C374 2113743E07 Capacitor Chip 0.022µF
C376 2113743N28 Capacitor Chip 12pF
C377 2113743N17 Capacitor Chip 4.3pF
C378 2113743N01 Capacitor Chip 0.5pF
C379 2113740A82 Capacitor Chip 1500pF
C380 2109720D14 Capacitor Chip 0.1µF
C381 2113743E20 Capacitor Chip 0.1µF
C382 2311049A59 Capacitor Tantalum 10µF
C383 2113743M08 Capacitor Chip 0.022µF
C384 2113743L13 Capacitor Chip 680pF
C385 2113743N25 Capacitor Chip 9.1pF
C386 to
C388
2113743N30 Capacitor Chip 15pF
C389 to
C390
2113743N29 Capacitor Chip 13pF
C391 2113741F49 Capacitor Chip 0.01µF
C392 2311049A07 Capacitor Tantalum 1µF
C393 2113743E20 Capacitor Chip 0.1µF
C394 2113743L13 Capacitor Chip 680pF
C400 2113743L41 Capacitor Chip 0.01µF
C401 to
C402
2113743M24 Capacitor Chip 0.1µF
C403 2113928D08 Capacitor Chip 10µF
C404 to
C405
2113743N50 Capacitor Chip 100pF
C406 to
C407
2113928N01 Capacitor Chip 0.1µF
Circuit
Ref
Motorola Part
No.
Description
