Motorola HT Series User Manual

900 MHz Circuit Board/Schematic Diagrams and Parts List (PCB 8485910Z01) 9-463
C408 2113743N50 Capacitor Chip 100pF
C409 2113743M24 Capacitor Chip 0.1µF
C410 2113928N01 Capacitor Chip 0.1µF
C411 2113743M24 Capacitor Chip 0.1µF
C412 2311049A59 Capacitor Tantalum 10µF
C414 2113743M24 Capacitor Chip 0.1µF
C415 2109720D01 Capacitor Chip 0.01µF
C416 2113928N01 Capacitor Chip 0.1µF
C419 2113928N01 Capacitor Chip 0.1µF
C420 2113743L41 Capacitor Chip 0.01µF
C421 2113928N01 Capacitor Chip 0.1µF
C422 2113743M24 Capacitor Chip 0.1µF
C423 2113743N50 Capacitor Chip 100pF
C424 2311049A59 Capacitor Tantalum 10µF
C425 2113743M24 Capacitor Chip 0.1µF
C426 to
C427
2113743N50 Capacitor Chip 100pF
C428 2113743M24 Capacitor Chip 0.1µF
C429 2113743M24 Capacitor Chip 0.1µF
C430 2113928N01 Capacitor Chip 0.1µF
C431 2113743N50 Capacitor Chip 100pF
C432 2113743N01 Capacitor Chip 0.5pF
C433 2113743L41 Capacitor Chip 0.01µF
C434 to
C435
2113743M24 Capacitor Chip 0.1µF
C436 to
C437
2113743N34 Capacitor Chip 22pF
C438 2113743F18 Capacitor Chip 2.2µF
C439 2113743L17 Capacitor Chip 1000pF
C440 2113743F18 Capacitor Chip 2.2µF
C441 2113743N50 Capacitor Chip 100pF
C442 2113743E20 Capacitor Chip 0.1µF
C443 2113928N01 Capacitor Chip 0.1µF
C444 to
C445
2113743N50 Capacitor Chip 100pF
C447 2113743M08 Capacitor Chip 0.022µF
C448 2113928N01 Capacitor Chip 0.1µF
C449 2113743N50 Capacitor Chip 100pF
C450 2113743M24 Capacitor Chip 0.1µF
C451 2113743M08 Capacitor Chip 0.022µF
C452 2113743B29 Capacitor Chip 1µF
C453 2113743N50 Capacitor Chip 100pF
C456 2113743N50 Capacitor Chip 100pF
C458 to
C459
2113743N50 Capacitor Chip 100pF
C463 2113743N50 Capacitor Chip 100pF
C466 2113743N50 Capacitor Chip 100pF
C467 2113928N01 Capacitor Chip 0.1µF
C471 to
C473
2113743N50 Capacitor Chip 100pF
C475 2113743H14 Capacitor Chip 10µF
C476 2113928D08 Capacitor Chip 10µF
C479 2113928N01 Capacitor Chip 0.1µF
C480 2113743G26 Capacitor Chip 4.7µF
C481 to
C482
2113928N01 Capacitor Chip 0.1µF
Circuit
Ref
Motorola Part
No.
Description
C490 to
C497
2113743N50 Capacitor Chip 100pF
C502 2311049A05 Capacitor Tantalum 0.47µF
C503 2113743N44 Capacitor Chip 56pF
C505 2113743N42 Capacitor Chip 47pF
C511 to
C514
2113743N42 Capacitor Chip 47pF
C520 2113743L41 Capacitor Chip 0.01µF
C521 to
C523
2113743L41 Capacitor Chip 0.01µF
C524 2113743N30 Capacitor Chip 15pF
C525 to
C529
2113743N46 Capacitor Chip 68pF
C530 2311049A18 Capacitor Tantalum 10µF
C531 2113743N46 Capacitor Chip 68pF
C801 2111049A05 Capacitor Tantalum 0.47µF
C802 to
C805
2109720D14 Capacitor Chip 0.1µF
C851 2113743G26 Capacitor Chip 4.7µF
C852 to
C853
2113743N44 Capacitor Chip 56pF
C854 2113743F16 Capacitor Chip 1µF
C855 2113743N42 Capacitor Chip 47pF
C856 2113743E20 Capacitor Chip 0.1µF
C857 2113743F16 Capacitor Chip 1µF
C858 2113743N42 Capacitor Chip 47pF
C859 to
C861
2113743L29 Capacitor Chip 3300pF
C862 2113743E20 Capacitor Chip 0.1µF
C863 2113743G26 Capacitor Chip 4.7µF
DIODE (SEE NOTE)
CR101 to
CR102
4880973Z02 Diode Pin MA4PH261
CR201 to
CR202
4802233J09 Diode Array IMN10
CR203 4802233J22 Diode Array 1T363
CR251 to
CR253
4862824C01 Diode Varactor 1SV229
CR300 4880154K03 Diode Schottky MMBD353LT1
CR301 4802245J41 Diode Switching HSMP3820
CR350 4862824C01 Diode VARACTOR 1SV229
CR411 to
CR413
4802245J62 Diode Array RB731U
CR412 to
CR413
4802245J62 Diode Array RB731U
CR440 4813833C02 Diode Dual Common Cathode
MMBD6100LT1
CR501 4880107R01 Diode Rectifier BYD17D
CR503 4805729G49 Opto-Device LED BRPY1204W
FERRITE BEADS
E101 2484657R01 2743019447
E102 2405688Z01 2744044446
E400 to
E409
2480640Z01 BK1005HM471
FUSE
F501 6580542Z01 Protector 1608FF
Circuit
Ref
Motorola Part
No.
Description
OSCILLATOR
FL251 PT48PNGA33 Resonator
FL252 4802245J57 Resonator DRR030KE1R225TC
FILTER
FL300 to
FL301
4802245J78 FILTER A0-L177-01
FL350 4885631B01 FILTER 31B01
FL401 4870368G02 Crystal
CONNECTOR
J101 2880658Z02 CONNECTOR
J400 0905505Y04 Connector Multi_pin
FH12-40S-0.5SH
J403 0905505Y02 CONNECTOR MULTI_PIN
CL586-0524-9
COIL, INDUCTOR
L101 2462587V26 Inductor 22nH
L102 2462587V26 Inductor 22nH
L103 2460591B80 Inductor Airwound 19.61nH
L104 2460591A13 Inductor Airwound 5.34nH
L105 2460591A13 Inductor Airwound 5.34nH
L106 2413926G12 Inductor 27nH
L107 to
L108
2413926G19 Inductor 100nH
L109 2460591A77 Inductor Airwound 10.40nH
L110 2413926G05 Inductor 6.8nH
L111 2413926G19 Inductor 100nH
L112 2413926G12 Inductor 27nH
L200 2462587Q20 Inductor 2.2µH
L202 2462587Q20 Inductor 2.2µH
L203 2462587V21 Inductor 6.8nH
L204 2462587P25 Inductor 12µH
L250 2413926G03 Inductor 4.7nH
L252 2413926G19 Inductor 100nH
L253 2462587V41 Inductor 390nH
L254 2413926G13 Inductor 33nH
L256 to
L260
2413926G19 Inductor 100nH
L261 2413926G09 Inductor 15nH
L262 2413926G19 Inductor 100nH
L263 2413926G11 Inductor 22nH
L264 2413926G06 Inductor 8.2nH
L265 2413926G15 Inductor 47nH
L301 2413926G02 Inductor 3.9nH
L302 2413926G19 Inductor 100nH
L303 2462587V41 Inductor 390nH
L304 2413926G08 Inductor 12nH
L306 2462587V32 Inductor 68nH
L307 2413926G12 Inductor 27nH
L308 2462587V30 Inductor 47nH
L309 2413926G19 Inductor 100nH
L310 2413926G01 Inductor 3.3nH
L311 2413926G05 Inductor 6.8nH
L350 2462587Q20 Inductor 2.2µH
L351 to
L352
2462587T22 Inductor 390nH
L353 2462587V34 Inductor 100nH
Circuit
Ref
Motorola Part
No.
Description
L354 2462587T23 Inductor 470nH
L355 2413923B04 Inductor 100nH
L356 2462587T44 Inductor 33nH
L357 2462587Q20 Inductor 2.2µH
L400 to
L401
2462587Q42 Inductor 390nH
L410 to
L411
2462587Q42 Inductor 390nH
L505 2462587Q42 Inductor 390nH
L851 2462587Q20 Inductor 2.2µH
M101 2680499Z01 Mechanical
PUSH BUTTON SWITCH
PB501 to
PB505
4080523Z01 Mechanical Switch KSS223G
TRANSISTOR (SEE NOTE)
Q101 4813828A09 Transistor FET MRF1517T1
Q201 to
Q202
4802245J50 Transistor Bipolar UMC5N
Q251 4805218N63 Transistor Bipolar BFQ67W
Q252 4802245J50 Transistor Bipolar UMC5N
Q302 4802245J56 Transistor Bipolar QSBT0048
Q304 4802245J44 Transistor Bipolar HP415
Q350 4805218N63 Transistor Bipolar BFQ67W
Q400 4809579E18 Transistor FET TP0101T
Q403 4880214G02 Transistor Bipolar MMBT3904L
Q405 4802245J54 Transistor Bipolar UMG5N
Q410 to
Q411
4802245J54 Transistor Bipolar UMG5N
Q416 4809579E18 Transistor FET TP0101T
Q417 4802245J50 Transistor Bipolar UMC5N
Q502 5180159R01 Transistor Bipolar IMX1
Q505 4880214G02 Transistor Bipolar MMBT3904L
RESISTOR, FIXED
R101 0680539Z01 Resistor Chip 0.1
R102 to
R103
0662057A34 Resistor Chip 240
R104 0662057M50 Resistor Chip 100
R105 0662057M54 Resistor Chip 150
R106 0662057A18 Resistor Chip 51
R108 0662057M85 Resistor Chip 3K
R109 0662057M81 Resistor Chip 2K
R110 0662057M98 Resistor Chip 10K
R111 0662057M02 Resistor Chip 1
R113 0662057M02 Resistor Chip 1
R114 0662057M26 Resistor Chip 10
R115 0662057N08 Resistor Chip 24K
R116 0662057M01 Resistor Chip 0
R117 0662057N39 Resistor Chip 470K
R118 0662057N30 Resistor Chip 200K
R119 0662057N05 Resistor Chip 18K
R120 0662057N09 Resistor Chip 27K
R121 0662057M01 Resistor Chip 0
R200 0662057M50 Resistor Chip 100
R202 0662057M88 Resistor Chip 3.9K
R203 0662057M38 Resistor Chip 33
R204 0662057M52 Resistor Chip 120
Circuit
Ref
Motorola Part
No.
Description
