900 MHz Circuit Board/Schematic Diagrams and Parts List (PCB 8471203M01) 9-481

C324 NOT PLACED

C331 2113944C51 CAP CER CHP 1000.OPF 50V

C333 2113945C31

CAP,FXD, 0.1UF,+10%,-

10%,50V-DC

C350 2113944A32 CAP CER CHP 39.0PF 5%

C351 2113944A24 CAP CER CHP 9.1PF

C352 2113944A22 CAP CER CHP 7.5PF

C353 2113944A37 CAP CER CHP 75.0PF 5%

C354 2113946K02 CAP CER CHP 0.10UF

C355 2113946K02 CAP CER CHP 0.10UF

C356 2113944A21 CAP CER CHP 6.8PF

C357 2113944A81 CAP,FXD,24PF, 5%

C358 NOT PLACED

C359 2113944A19 CAP CER CHP 5.6PF

C360 2113944A78 CAP,FXD,13PF, 5%

C361 2113946K02 CAP CER CHP 0.10UF

C362 2113946K02 CAP CER CHP 0.10UF

C363 2113945B05 CAP,FXD, 0.033UF, 10%

C364 2113945B05 CAP,FXD, 0.033UF, 10%

C365 2113944A78 CAP,FXD,13PF, 5%

C366 2113944A31 CAP CER CHP 33.0PF 5%

C367 2113944A27 CAP CER CHP 15.0PF 5%

C368 NOT PLACED

C369 2113946N03 CAP CER CHP 2.2UF

C370 2313960B57 CAP,FXD, 10UF,10%

C371 2113946B04 CAP CER CHP 0.10UF 10%

C372 2113945B05 CAP,FXD, 0.033UF, 10%

C373 2113946B04 CAP CER CHP 0.10UF 10%

C374 2113946B04 CAP CER CHP 0.10UF 10%

C375 2113945A14 CAP,FXD,4700PF, 5%

C376 2113946B04 CAP CER CHP 0.10UF 10%

C377 2113946B04 CAP CER CHP 0.10UF 10%

C378 2113946B04 CAP CER CHP 0.10UF 10%

C379 2113946B04 CAP CER CHP 0.10UF 10%

C380 2113944A41 CAP CER CHP 120.0PF 5%

C381 2113946B04 CAP CER CHP 0.10UF 10%

C382 NOT PLACED

C383 NOT PLACED

C384 NOT PLACED

C385 2113944A24 CAP CER CHP 9.1PF

C388 2113944C81 CAP,FXD,24PF, 5%

C389 2113944A24 CAP CER CHP 9.1PF

C390 2113944C81 CAP,FXD,24PF, 5%

C391 2113944A44

CAP CER CHP 220.0 PF 50V

C392 2113944A81 CAP,FXD,24PF, 5%

Circuit

Ref

Motorola Part

No.

Description

C393 2113944C81 CAP,FXD,24PF, 5%

C395 2113944A21

CAP CER CHP 6.8PF 50V +/-

0.5PF

C396 2113944A44

CAP CER CHP 220.0 PF 50V

C397 2113944A79

CAP,FXD,16PF,+5%,-5%,50V-

DC,0402

C398 NOT PLACED

C400 2113945B02 CAP CER CHP 10,000PF 10%

C401 2113946K02 CAP CER CHP 0.10UF

C402 2113946K02 CAP CER CHP 0.10UF

C403 2113946R01 CAP CER CHP 10.0UF

C404 2113944A34 CAP CER CHP 56.0PF 5%

C405 2113944A34 CAP CER CHP 56.0PF 5%

C406 NOT PLACED

C407 2113946B04 CAP CER CHP 0.10UF 10%

C408 2113944A34 CAP CER CHP 56.0PF 5%

C409 2113946K02 CAP CER CHP 0.10UF

C410 2113946B04 CAP CER CHP 0.10UF 10%

C411 2113946K02 CAP CER CHP 0.10UF

C412 2313960B57 CAP,FXD,10UF, 10%

C414 2113946K02 CAP CER CHP 0.10UF

C415 2185895Z01 CAP CER LOW DIST .01UF

C416 2113946B04 CAP CER CHP 0.10UF 10%

C419 NOT PLACED

C420 2113945B02 CAP CER CHP 10,000PF 10%

C421 2113946B04 CAP CER CHP 0.10UF 10%

C422 2113946K02 CAP CER CHP 0.10UF

C423 2113944A34 CAP CER CHP 56.0PF 5%

C424 2313960B57 CAP,FXD,10UF, 10%

C425 2113946K02 CAP CER CHP 0.10UF

C426 2113944A34 CAP CER CHP 56.0PF 5%

C427 2113944A34 CAP CER CHP 56.0PF 5%

C428 2113946K02 CAP CER CHP 0.10UF

C429 2113946K02 CAP CER CHP 0.10UF

C430 2113946B04 CAP CER CHP 0.10UF 10%

C431 2113944A34 CAP CER CHP 56.0PF 5%

C432 NOT PLACED

C433 2113945B02 CAP CER CHP 10,000PF 10%

C434 NOT PLACED

C435 2113946K02 CAP CER CHP 0.10UF

C436 NOT PLACED

C437 NOT PLACED

C438 2113946N03 CAP CER CHP 2.2UF

C439 2113945A09 CAP CER CHP 1000PF 10%

C440 2113946N03 CAP CER CHP 2.2UF

Circuit

Ref

Motorola Part

No.

Description

C441 2113944A34 CAP CER CHP 56.0PF 5%

C442 2113945C31 CAP,FXD, 0.1UF, 10%

C443 2113946B04 CAP CER CHP 0.10UF 10%

C444 2113944A34 CAP CER CHP 56.0PF 5%

C445 2113944A34 CAP CER CHP 56.0PF 5%

C447 2113945B04 CAP,FXD,0.022UF, 10%

C448 2113946B04 CAP CER CHP 0.10UF 10%

C449 2113944A34 CAP CER CHP 56.0PF 5%

C450 NOT PLACED

C451 2113945B04 CAP,FXD,0.022UF, 10%

C452 NOT PLACED

C453 2113944A34 CAP CER CHP 56.0PF 5%

C456 2113944A34 CAP CER CHP 56.0PF 5%

C458 2113944A34 CAP CER CHP 56.0PF 5%

C459 2113944A34 CAP CER CHP 56.0PF 5%

C463 2113944A34 CAP CER CHP 56.0PF 5%

C466 2113944A34 CAP CER CHP 56.0PF 5%

C467 2113946B04 CAP CER CHP 0.10UF 10%

C471 2113944A34 CAP CER CHP 56.0PF 5%

C472 2113944A34 CAP CER CHP 56.0PF 5%

C473 2113944A34 CAP CER CHP 56.0PF 5%

C475 2113956E91 CAP,FXD,10UF, 10%

C476 2113946R01 CAP CER CHP 10.0UF

C479 2113946B04 CAP CER CHP 0.10UF 10%

C480 2113946Q01 CAP CER CHP 4.7UF

C481 2113946B04 CAP CER CHP 0.10UF 10%

C482 2113946B04 CAP CER CHP 0.10UF 10%

C490 2113944A34 CAP CER CHP 56.0PF 5%

C491 2113944A34 CAP CER CHP 56.0PF 5%

C492 2113944A34 CAP CER CHP 56.0PF 5%

C493 2113944A34 CAP CER CHP 56.0PF 5%

C494 2113944A34 CAP CER CHP 56.0PF 5%

C495 2113944A34 CAP CER CHP 56.0PF 5%

C496 2113944A34 CAP CER CHP 56.0PF 5%

C497 2113944A34 CAP CER CHP 56.0PF 5%

C502 2313960A55 CAP,FXD, 0.47UF, 10%

C503 2113944A34 CAP CER CHP 56.0PF 5%

C505 2113944A33 CAP CER CHP 47.0PF 5%

C511 2113944A33 CAP CER CHP 47.0PF 5%

C512 2113944A33 CAP CER CHP 47.0PF 5%

C513 2113944A33 CAP CER CHP 47.0PF 5%

C514 2113944A33 CAP CER CHP 47.0PF 5%

C520 2113945B02 CAP CER CHP 10,000PF 10%

C521 2113945B02 CAP CER CHP 10,000PF 10%

C522 2113945B02 CAP CER CHP 10,000PF 10%

C523 2113945B02 CAP CER CHP 10,000PF 10%

C524 2113944A27 CAP CER CHP 15.0PF 5%

Circuit

Ref

Motorola Part

No.

Description

C525 2113944A36 CAP CER CHP 68.0PF 5%

C526 2113944A36 CAP CER CHP 68.0PF 5%

C527 2113944A36 CAP CER CHP 68.0PF 5%

C528 2113944A36 CAP CER CHP 68.0PF 5%

C529 2113944A36 CAP CER CHP 68.0PF 5%

C530 2313960F04 CAP,FXD, 33UF, 10%

C531 2113944A36 CAP CER CHP 68.0PF 5%

C801 2313960A55 CAP,FXD, 0.47UF, 10%

C802 NOT PLACED

C803 NOT PLACED

C804 NOT PLACED

C805 NOT PLACED

C851 2113946Q01 CAP CER CHP 4.7UF

C852 2113944A34 CAP CER CHP 56.0PF 5%

C853 2113944A34 CAP CER CHP 56.0PF 5%

C855 2113944A33 CAP CER CHP 47.0PF 5%

C856 2113945C31 CAP,FXD, 0.1UF, 10%

C857 2313960D80 CAP,FXD, 47UF, 10%

C858 2113944A33 CAP CER CHP 47.0PF 5%

C859 2113945A12 CAP CER CHP 3300PF 10%

C860 2113945A12 CAP CER CHP 3300PF 10%

C861 2113945A12 CAP CER CHP 3300PF 10%

C862 2113945C31 CAP,FXD, 0.1UF, 10%

C863 2113946Q01 CAP CER CHP 4.7UF

CR101 4880973Z02 PIN DIODE

CR102 4880973Z02 PIN DIODE

CR201 4815011H01 DIODE TRIPLE

CR202 4815011H01 DIODE TRIPLE

CR203 NOT PLACED

CR251 4885055Y01 DIODE VARACTOR

CR252 4885055Y01 DIODE VARACTOR

CR253 4885055Y01 DIODE VARACTOR

CR300 4815048H01 SOT MMBD353 DIODE

CR350 4815048H01 SOT MMBD353 DIODE

CR411 4815067H01 DIODE SCHOTTKY, RB731U

CR412 4815067H01 DIODE SCHOTTKY, RB731U

CR413 4815067H01 DIODE SCHOTTKY, RB731U

CR440 4813978C02 DISCRETE RECTIFIERS

CR501 4815155H01 RECTIFIER

CR503 4805729G49 DIODE RED/YEL

E101 2415954H01 INDUCTOR BEAD CHIP

E102 2405688Z01 FERRITE BEAD

E400 2480640Z01 FERRITE BEAD

E401 2480640Z01 FERRITE BEAD

E402 2480640Z01 FERRITE BEAD

E403 2480640Z01 FERRITE BEAD

Circuit

Ref

Motorola Part

No.

Description
