Motorola HT Series

9-482 900 MHz Circuit Board/Schematic Diagrams and Parts List (PCB 8471203M01)
E404 2480640Z01 FERRITE BEAD
E405 2480640Z01 FERRITE BEAD
E406 2480640Z01 FERRITE BEAD
E407 2480640Z01 FERRITE BEAD
E408 2480640Z01 FERRITE BEAD
E409 2480640Z01 FERRITE BEAD
F501 6515076H01 FUSE CHIP 3A
FL251 4885426C23 CER RESONATOR 960 MHZ
FL252 4802245J57
COAXIAL CERAMIC
INDUCTOR
FL300 4802245J78 RX 3-POLE BANDPASS FLTR
FL301 4802245J78 RX 3-POLE BANDPASS FLTR
FL350 9116854H01
73.35 MHZ 4 POLE XTAL
FLTR
FL351 9116854H01
73.35 MHZ 4 POLE XTAL
FLTR
FL352 9115811H01 SMD455KHZ 6 ELEMENT
FL353 9180468V04
455KHZ 4 ELEMENT CER
FLTR
FL401 NOT PLACED
-
J101 2880658Z06 CONN,SMA,RCPT
J400 0915064H03 CONNECTOR, ZIF (40 PINS)
J403 0915064H02 ZIF (20 PINS)
L101 2414032F26 IDCTR,WW,22NH,5%
L102 2414032F26 IDCTR,WW,22NH,5%
L103 2479990B02 COIL AIR WND IDCTR 19.61
L104 2460591A13 COIL AIR WND IDCTR 5.34
L105 2460591A13 COIL AIR WND IDCTR 5.35
L106 NOT PLACED
-
L107 2414017G19 IDCTR,CHIP,100NH,5%
L108 2414017G19 IDCTR,CHIP,100NH,5%
L109 2460591A77 COIL AIR WND IDCTR 10.40
L110 2414017G05 IDCTR,CHIP,6.8NH,5%
L111 2414017G19 IDCTR,CHIP,100NH,5%
L112 2414017G12 IDCTR,CHIP,27NH,5%
L200 2414017Q20 IDCTR,FXD,2.2UH,20%
L202 2414017Q20 IDCTR,FXD,2.2UH,20%
L203 2414032F21 IDCTR,WW,6.8NH,5%
L204 2414032L25 IDCTR,WW,12UH,5%
L250 2414017G03 IDCTR,CHIP,4.7NH
L252 2414017G19 IDCTR,CHIP,100NH,5%
L253 2414032F41 IDCTR,WW,390NH,10%
L254 2414017G08 IDCTR,CHIP,12NH,5%
L256 2414017G19 IDCTR,CHIP,100NH,5%
L257 2414017G19 IDCTR,CHIP,100NH,5%
L258 2414017G19 IDCTR,CHIP,100NH,5%
L259 2414017G19 IDCTR,CHIP,100NH,5%
Circuit
Ref
Motorola Part
No.
Description
L260 2414017G19 IDCTR,CHIP,100NH,5%
L261 2414017G09 IDCTR,CHIP,15NH,5%
L262 2414017G19 IDCTR,CHIP,100NH,5%
L263 2414017G11 IDCTR,CHIP,22NH,5%
L264 2414017G06 IDCTR,CHIP,8.2NH,5%
L265 2414017G15 IDCTR,CHIP,47NH,5%
L266 NOT PLACED
-
L301 2414017N11 IDCTR,CHIP,8.2NH,5%
L302 2414017N13 IDCTR,CHIP,12NH,5%
L303 NOT PLACED
-
L304 2414017G10 IDCTR,CHIP,18NH,5%
L305 2415429H47 CHIP IDCTR, WW, 390NH, 5%
L306 2414032B55 IDCTR,WW,150NH,5%
L307 2414017G11 IDCTR,CHIP,22NH,5%
L308 2414032F28 IDCTR,WW,33NH,5%
L309 2414017G19 IDCTR,CHIP,100NH,5%
L310 2414017G01 IDCTR,CHIP,3.3NH
L311 2414017G05 IDCTR,CHIP,6.8NH,5%
L350 NOT PLACED
-
L351 2414032D21 IDCTR,WW,330NH,5%
L352 2414032D21 IDCTR,WW,330NH,5%
L353 2414032D22 IDCTR,WW,390NH,5%
L354 2414015A13 IDCTR,FXD,560NH,2%
L355 NOT PLACED
-
L400 2414017Q42 IDCTR,FXD,390NH,10%
L401 2414017Q42 IDCTR,FXD,390NH,10%
L410 2414017Q42 IDCTR,FXD,390NH,10%
L411 2414017Q42 IDCTR,FXD,390NH,10%
L420 2415429H26 CHIP IDCTR, 33NH, 5%
L505 2414017Q42 IDCTR,FXD,390NH,10%
L851 2414017Q20 IDCTR,FXD,2.2UH,20%
M101 2680499Z02 HEAT SPREADER
PB501 4086470Z01 TACT SWITCH
PB502 4086470Z01 TACT SWITCH
PB503 4086470Z01 TACT SWITCH
PB504 4086470Z01 TACT SWITCH
PB505 4086470Z01 TACT SWITCH
Q101 4813976A03 450MHZ 8W 7.5V PLD-1.5 T&R
Q201 4815055H01 TSTR DUAL NPN/PNP
Q202 4815055H01 TSTR DUAL NPN/PNP
Q251 4805218N63 RF TRANS SOT 323 BFQ67W
Q252 4815055H01 TSTR DUAL NPN/PNP
Q253 NOT PLACED
Q301 4815267H01 DBRT UMT1NFTN
Q302 4802247J01 BJT, RF AMP, BFS505
Q304 4816531H01 NPN BIPOLAR TRANSISTOR
Circuit
Ref
Motorola Part
No.
Description
Q350 4802197J95 RF TRANSISTOR PBR941
Q351 4802197J95 RF TRANSISTOR PBR941
Q352 4813973M07 XSTR,BIP GP SS,NPN,T3904
Q400 4815069H02 TSTR MOSFET P-CHAN
Q403 4813973M07 XSTR,BIP GP SS,NPN,T3904
Q405 4815066H01
UMG5N DIGITAL
TRANSISTOR
Q410 4815066H01
UMG5N DIGITAL
TRANSISTOR
Q411 NOT PLACED
-
Q416 NOT PLACED
-
Q417 4815055H01 TSTR DUAL NPN/PNP UMH 5
Q502 4815154H01 DUAL TRANS NPN
Q505 4813973M07 XSTR,BIP GP SS,NPN,T3904
R101 0615043C01 RES POWER METAL STRIP
R102 0613952H58 CER CHIP RES 240 OHM 5%
R103 0613952H58 CER CHIP RES 240 OHM 5%
R104 NOT PLACED
-
R105 0613952Q53 CER CHIP RES 150 OHM 5%
R106 0613952H42 CER CHIP RES 51.0 OHM 5%
R108 0613952Q84 CER CHIP RES 3000 OHM 5%
R109 0613952Q80 CER CHIP RES 2000 OHM 5%
R110 0613952R01 CER CHIP RES 10K OHM 5%
R111 0613952Q01 CER CHIP RES 1.0 OHM 5%
R113 0613952Q01 CER CHIP RES 1.0 OHM 5%
R114 0613952Q25 CER CHIP RES 10.0 OHM 5%
R115 0613952R10 CER CHIP RES 24K OHM 5%
R116 0613952R66 CER CHIP RES 0.0 OHM
R117 0613952R41 CER CHIP RES 470K OHM 5%
R118 0613952R32 CER CHIP RES 200K OHM 5%
R119 0613952R07 CER CHIP RES 18K OHM 5%
R120 0613952R11 CER CHIP RES 27K OHM 5%
R121 0613952R66 CER CHIP RES 0.0 OHM
R200 0613952Q49 CER CHIP RES 100 OHM 5%
R202 0613952Q87 CER CHIP RES 3900 OHM 5%
R203 0613952Q37 CER CHIP RES 33.0 OHM 5%
R204 0613952Q51 CER CHIP RES 120 OHM 5%
R206 0613952R12 CER CHIP RES 30K OHM 5%
R208 0613952R12 CER CHIP RES 30K OHM 5%
R209 0613952Q77 CER CHIP RES 1500 OHM 5%
R210 0613952Q69 CER CHIP RES 680 OHM 5%
R211 NOT PLACED
-
R212 NOT PLACED
-
R213 0613952Q49 CER CHIP RES 100 OHM 5%
R214 0613952R17 CER CHIP RES 47K OHM 5%
R218 0613952R13 CER CHIP RES 33K OHM 5%
Circuit
Ref
Motorola Part
No.
Description
R219 0613952Q53 CER CHIP RES 150 OHM 5%
R220 0613952Q53 CER CHIP RES 150 OHM 5%
R222 NOT PLACED
-
R223 0613952R66 CER CHIP RES 0.0 OHM
R250 0613952Q59 CER CHIP RES 270 OHM 5%
R251 0613952Q49 CER CHIP RES 100 OHM 5%
R253 0613952Q25 CER CHIP RES 10.0 OHM 5%
R254 0613952R17 CER CHIP RES 47K OHM 5%
R255 0613952Q61 CER CHIP RES 330 OHM 5%
R257 0613952Q73 CER CHIP RES 1000 OHM 5%
R261 0613952Q37 CER CHIP RES 33.0 OHM 5%
R262 0613952Q37 CER CHIP RES 33.0 OHM 5%
R263 0613952Q59 CER CHIP RES 270 OHM 5%
R264 0613952Q59 CER CHIP RES 270 OHM 5%
R265 0613952R07 CER CHIP RES 18K OHM 5%
R266 0613952R11 CER CHIP RES 27K OHM 5%
R267 0613952R03 CER CHIP RES 12K OHM 5%
R268 0613952R09 CER CHIP RES 22K OHM 5%
R270 0613952Q37 CER CHIP RES 33.0 OHM 5%
R271 0613952Q37 CER CHIP RES 33.0 OHM 5%
R272 0613952Q37 CER CHIP RES 33.0 OHM 5%
R273 0613952Q37 CER CHIP RES 33.0 OHM 5%
R274 0613952Q51 CER CHIP RES 120 OHM 5%
R275 0613952Q25 CER CHIP RES 10.0 OHM 5%
R280 NOT PLACED
-
R281 0613952R66 CER CHIP RES 0.0 OHM
R282 NOT PLACED
-
R306 0613952Q91 CER CHIP RES 5600 OHM 5%
R307 0613952R11 CER CHIP RES 27K OHM 5%
R309 2113944A36 CAP CER CHP 68.0PF 5%
R310 0613952Q91 CER CHIP RES 5600 OHM 5%
R312 0613952Q45 CER CHIP RES 68.0 OHM 5%
R314 0613952Q91 CER CHIP RES 5600 OHM 5%
R316 0613952R19 CER CHIP RES 56K OHM 5%
R317 0613952R25 CER CHIP RES 100K OHM 5%
R318 0613952R25 CER CHIP RES 100K OHM 5%
R319 0613952R29 CER CHIP RES 150K OHM 5%
R320 0613952Q42 CER CHIP RES 51.0 OHM 5%
R322 NOT PLACED
-
R323 0613952Q86 CER CHIP RES 3600 OHM 5%
R324 0613952Q67 CER CHIP RES 560 OHM 5%
R325 0613952R12 CER CHIP RES 30K OHM 5%
R326 0613952Q25 CER CHIP RES 10.0 OHM 5%
R327 0613952Q39 CER CHIP RES 39.0 OHM 5%
R328 0613952R05 CER CHIP RES 15K OHM 5%
R329 NOT PLACED
-
Circuit
Ref
Motorola Part
No.
Description
