900 MHz Circuit Board/Schematic Diagrams and Parts List (PCB 8471203M01) 9-483
* Motorola Depot Servicing only
R330 0613952R25 CER CHIP RES 100K OHM 5%
R331 0613952R29 CER CHIP RES 150K OHM 5%
R334 NOT PLACED
-
R335 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R350 0613952R03 CER CHIP RES 12K OHM 5%
R351 0613952Q25 CER CHIP RES 10.0 OHM 5%
R352 0613952Q93 CER CHIP RES 6800 OHM 5%
R353 0613952R11 CER CHIP RES 27K OHM 5%
R354 0613952Q68 CER CHIP RES 620 OHM 5%
R355 0613952Q49 CER CHIP RES 100 OHM 5%
R356 0613952R03 CER CHIP RES 12K OHM 5%
R357 0613952Q25 CER CHIP RES 10.0 OHM 5%
R358 0613952Q93 CER CHIP RES 6800 OHM 5%
R359 0613952R02 CER CHIP RES 11K OHM 5%
R360 0613952Q61 CER CHIP RES 330 OHM 5%
R361 0613952Q63 CER CHIP RES 390 OHM 5%
R362 0613952Q61 CER CHIP RES 330 OHM 5%
R363 0613952Q42 CER CHIP RES 51.0 OHM 5%
R364 0613952Q71 CER CHIP RES 820 OHM 5%
R365 NOT PLACED
-
R366 0613952Q79 CER CHIP RES 1800 OHM 5%
R367 0613952R03 CER CHIP RES 12K OHM 5%
R368 0613952R01 CER CHIP RES 10K OHM 5%
R369 0613952Q69 CER CHIP RES 680 OHM 5%
R370 0613952R03 CER CHIP RES 12K OHM 5%
R371 0613952Q79 CER CHIP RES 1800 OHM 5%
R372 0613952Q63 CER CHIP RES 390 OHM 5%
R373 0613952Q75 CER CHIP RES 1200 OHM 5%
R374 0613952Q85 CER CHIP RES 3300 OHM 5%
R375 0613952Q82 CER CHIP RES 2400 OHM 5%
R376 0613952R66 CER CHIP RES 0.0 OHM
R377 NOT PLACED
-
R379 NOT PLACED
-
R400 0613952R17 CER CHIP RES 47K OHM
R401 0613952R66 CER CHIP RES 0.0 OHM
R402 NOT PLACED
-
R403 NOT PLACED
-
R405 0613952R66 CER CHIP RES 0.0 OHM
R406 0613952R22 CER CHIP RES 75K OHM
R407 0613952R21 CER CHIP RES 68K OHM
R408 NOT PLACED
-
R409 0613952R01 CER CHIP RES 10K OHM
R410 0613952R25 CER CHIP RES 100K OHM
R411 0613952R01 CER CHIP RES 10K OHM
R413 0613952R66 CER CHIP RES 0.0 OHM
Circuit
Ref
Motorola Part
No.
Description
R414 0613952Z75 RES,MF,180KOHM
R415 0613952Z72 RES,MF,91KOHM
R416 0613952Q89 CER CHIP RES 4700 OHM
R418 NOT PLACED
-
R419 NOT PLACED
-
R420 NOT PLACED
-
R421 0613952Q80 CER CHIP RES 2000 OHM
R423 0613952R41 CER CHIP RES 470K OHM
R424 0613952R14 CER CHIP RES 36K OHM
R425 0613952R12 CER CHIP RES 30K OHM
R426 NOT PLACED
-
R427 0613952Q83 CER CHIP RES 2700 OHM
R428 0613952Q09 CER CHIP RES 2.2 OHM
R429 0613952R01 CER CHIP RES 10K OHM
R431 0613952R41 CER CHIP RES 470K OHM
R432 0613952R18 CER CHIP RES 51K OHM
R434 0613952Q61 CER CHIP RES 330 OHM
R435 0613952Q80 CER CHIP RES 2000 OHM
R436 0613952Q73 CER CHIP RES 1000 OHM
R437 0613952R66 CER CHIP RES 0.0 OHM
R438 0613952Q53 CER CHIP RES 150 OHM
R439 0613952Q53 CER CHIP RES 150 OHM
R445 0613952R10 CER CHIP RES 24K OHM
R446 0613952R24 CER CHIP RES 91K OHM
R447 0613952R40 CER CHIP RES 430K OHM
R448 0613952R08 CER CHIP RES 20K OHM
R449 0613952R10 CER CHIP RES 24K OHM
R450 0613959Y45 CER CHIP RES 68 OHM
R457 0613952R01 CER CHIP RES 10K OHM
R460 0613952Q89 CER CHIP RES 4700 OHM
R461 NOT PLACED
-
R462 NOT PLACED
-
R463 0613952Q60 CER CHIP RES 300 OHM
R471 0613952R08 CER CHIP RES 20K OHM
R472 0613952R14 CER CHIP RES 36K OHM
R473 0613952Q25 CER CHIP RES 10.0 OHM
R475 0613952R66 CER CHIP RES 0.0 OHM
R476 0613952R10 CER CHIP RES 24K OHM
R477 0613952Q73 CER CHIP RES 1000 OHM
R478 0613952R01 CER CHIP RES 10K OHM
R481 0613952R10 CER CHIP RES 24K OHM
R492 0613952R66 CER CHIP RES 0.0 OHM
R499 NOT PLACED
-
R501 0613952Q69 CER CHIP RES 680 OHM 5%
R502 0613952Q55 CER CHIP RES 180 OHM 5%
R505 0613952R01 CER CHIP RES 10K OHM 5%
Circuit
Ref
Motorola Part
No.
Description
R506 0613952R17 CER CHIP RES 47K OHM 5%
R507 0613952R66 CER CHIP RES 0.0 OHM
R600 0613952J02 CER CHIP RES 11K OHM
R851 NOT PLACED
-
R852 0613952Q84 CER CHIP RES 3000 OHM 5%
R853 0613952Q77 CER CHIP RES 1500 OHM 5%
R854 0613952Q73 CER CHIP RES 1000 OHM 5%
R855 0613952R25 CER CHIP RES 100K OHM 5%
R856 0613952R66 CER CHIP RES 0.0 OHM
R857 0613952Q89 CER CHIP RES 4700 OHM 5%
R858 0613952R01 CER CHIP RES 10K OHM 5%
RT400 0680590Z01 THERMISTOR_33K
S501 4080710Z21 SWITCH, FREQUENCY
S502 1880619Z06 POTENTIOMETER, VOLUME
SH100 2680507Z02 SHIELD, HARMONIC FILTER
SH101 2615144H04 SHIELD, TRANSMITTER
SH102 2680554Z02 SHIELD, RX FRONT END TOP
SH201 2680511Z02 SHIELD, SYNTHESIZER
SH202 2680511Z02 SHIELD, SYNTHESIZER
SH250 2680514Z02 SHIELD, VCO BOTTOM/LVZIF
SH251 2680508Z02 SHIELD, LVZIF 2ND LO
SH252 2680508Z02 SHIELD, LVZIF 2ND LO
SH301 2680554Z02 SHIELD, RX FRONT END TOP
SH303 2686708Z03 SHIELD, COUPLER
SH350 2686528Z02 SHIELD, IF SECTION
SH351 2686707Z02 SHIELD, SM SLDRD
SH400 2680505Z02 SHIELD, CTRL TOP LEFT
SH401 2680506Z02 SHIELD, CTRL TOP RIGHT
SH402 2680515Z02
SHIELD, CTRL BOTTOM
LEFT
SH403 2680516Z02 SHIELD, CTRL BTM RIGHT
U101 5115678H01 LDMOS DRIVER IC
U102 5185765B26 IC PWR CTRL IN MOS20
U103 5115022H01 IC TEMPERATURE SENSOR
U201 5185177Y01 IC TESTED AT25016 48 PIN
U202 5115026H01 MAX SUPPLY VOL 16V
U203 5115019H01 3.3V REGULATOR
U250 5171121L01
LOW VOLTAGE VCO BUFFER
IC
U301 5171756L01 HMIC MIXER IC
U350 5115281H01 FM IF IC SA616
U351 5114005A01
IC,OP AMP,2PER
PKG,GP,SM,SO-8,PB-FREE
U400 5115012H01 MAX SUPPLY VOL 30V
U404 5115062H01 IC ASFIC_CMP
U405 5115020H01 STATIC_RAM_32KX8
U406 5115034H01 IC FLASH 4MBIT
Circuit
Ref
Motorola Part
No.
Description
U407 5115033H01 16K X 8 SPI SERIAL ROM
U409 5185143E03 HC11FL0 (3V) ASIC MICRO-P
U410 NOT PLACED
-
U420 5115280H01
AUDIO AMPLIFIER
TDA8547TS
U851 5105835U50 HEAR CLEAR IC
VR101 4813977M11 ZENER DIODE,MBZ5232
VR432 4813979P10 DIODE ARRAY
VR433 4813979P10 DIODE ARRAY
VR434 4815038H01 ZENER DIODE-6.8V
VR445 4813977A54 ZENER DIODE, MM3Z10V
VR446 4813977A54 ZENER DIODE, MM3Z10V
VR447 4813977A54 ZENER DIODE, MM3Z10V
VR448 4813977A54 ZENER DIODE, MM3Z10V
VR449 4813977A54 ZENER DIODE, MM3Z10V
VR450 4815040H01 ZENER DIODE-12V
VR501 4813977M14 ZENER DIODE,MBZ5235
VR502 4813977M21 ZENER DIODE,MBZ5242
VR503 4815038H01 ZENER DIODE-6.8V
VR504 4815038H01 ZENER DIODE-6.8V
VR505 4815038H01 ZENER DIODE-6.8V
VR506 4815038H01 ZENER DIODE-6.8V
VR507 4815038H01 ZENER DIODE-6.8V
VR508 4815038H01 ZENER DIODE-6.8V
Y200 4802245J68 OSC, REF 16.8 MHZ 1.5 PPM
Y201 NOT PLACED
-
Y350 4880606B10 2ND OSC XTAL 72.895 MHZ
Y351 9186145B02
CER.DISCR. CDBCA455CX36-
TC
Circuit
Ref
Motorola Part
No.
Description
