6-4
4.0 Specifications
General
VHF
Frequency: 150-174 MHz
Channel Capacity: 16
Power Supply: 7.5 Volts ±20%
Dimensions with 118mm x 56mm x 37mm
Standard High
Capacity NiMH
Battery:
Weight with 350g
Standard High
Capacity NiMH
Battery:
Sealing: Passes rain testing per
IPX4 (EN60529=1991)
Shock and Meets MIL STD 810C, D
Vibration: E and F
Dust: Meets MIL STD 810C, D
E and F
Humidity: Meets MIL STD 810C, D
E and F
Specifications
Transmitter
VHF
Channel Spacing 12.5/25 kHz
Freq. Stability 0.00025%
(-30°C to +60°C)
Spurs/Harmonics: -26 dBm
Audio Response: +1, -3 dB
(from 6 dB/oct. Pre-
Emphasis, 300 to
3000Hz)
Audio Distortion: <5%
@ 1000 Hz, 60%
Rated Max. Dev.
FM Noise: 40dB
Receiver
Hum and Noise 40 dB
Audio Distortion < 5%
Conducted -57 dBm
Emission
Audio Output 500 mW
@ <5% Distortion
All specifications are subject to change without notice.
