December 2, 2003 6881096C46-O
1-2 Introduction: Siren P/A Description
Some Siren/PA features can be programmed by a qualified radio technician using the Customer
Programming Software (CPS). A summary of available features for each Siren/PA configuration is
shown in Table 1-1.
Table 1-1. Siren/PA Features
Feature Using the Control Head Using the DEK-Plus
Wail/Yelp/Hi-lo tones
Yes Yes
“Airhorn” tone
Yes Yes
Siren manual tones
No No
Public address
Yes Yes
External radio
Yes Yes
PA volume control
Yes Yes
Siren power control
Automatic Automatic
Speaker short protection
Yes Yes
Programmable parameters
(using the radio codeplug)
Yes Yes
Power-up self check
Yes Yes
Horn-Ring override
No No
Siren State retained (while radio off)
No* No*
* Not available in initial offering.
