Table 1-2. Electrical Characteristics (Continued)
Characteristic
RF Wattmeter
(Autoranging display)
Frequency range:
Power range:
Accuracy:
Protection
General
Spectrum Analyzer
Dynamic range
Frequency
Range
Full scale frequency
dispersion:
Oscilloscope
Description
1
MHz
to
1000 MHz
1.0 watts to 125 wattts
±10%, 1 watt to 125 watts
Over temp indicator
>75 dB displayed, - 105 dBm to +30 dBm input range
with step attenuator
4 MHz to 1,000MHz
Adjustable between 1 MHz and 10 MHz
1-3
Duplex Generator
Frequency offset
Modulation level (FM only)
Adjustable from 0 to 10 MHz plus fixed offset of
45 MHz (high or low side)
Adjustable from 0 to 20 kHz peak deviation
Size
Frequency response
External vertical input range
Sweep rates
Sync
8 cm x
10
cm
DC to 0.5 MHz (3 dB point)
10 mV, 100 mV, 1V, 10V (per division)
1 [1 s, 10 H s, 0.1 ms, 1 ms, 0.01S, 0.18 (per division)
Automatic or normal triggering
Frequency Counter
Frequency range
Readout
Input sensitivity
10 Hz to
35
MHz
5 digit, autoranging
30 mV from 10 Hz to 1 MHz
50 mV from 1 MHz to 35 MHz
