Motorola R-2001A - Input;Output Characteristics

Table 1-2. Electrical Characteristics (Continued)
Characteristic
Manual Frequency Scan
Step size
Step rate
Time Base
Standard TCXO
Optional ovenized high
stability
Power and Environmental
AC
DC
Optional battery
Temperature range
Table 1-3. Input/Output Characteristics
Characteristic
Input
Ext mod in
Mic.
Ext Horiz
Vert/Sinad/DVM/Counter In
Description
Switch Selectable: 100 Hz, 1 kHz, 10 kHz, 100 kHz and
1 MHz (+ or-)
5 steps/sec.
Aging: ±1 x 10-° per year
Temp: ±1 x 10-
6
maximum error over the 0° to 55° C
temp. range
Aging: ±1 x 10-
6
per year
Temp: +5 x 10-
8
maximum error over the 0° to 55°C
temp range (warmup to ±5 x 10~
7
of final frequency
within 20 minutes)
100-130 VAC, 200-260 VAC 47-63 Hz
+11.5 VDC to +16 VDC
13.6V battery - provides 1 hour continuous operation
0° to 55°C operating; -40 to 85° C storage
Description
10K ohms nominal, 150 mV typical for 20 kHz dev. FM or
80% AM
Mic input provides bias and IDC limiting suitable for
Motorola RTM 9000A handset. PTT switches R2001 from
monitor to generate.
1 volt minimum for full screen deflection. Maximum input
10 volts.
1 Meg ohm, 40 pf Nominal; ±300 volts DC max, 300 Vrms
max at frequencies below 500 Hz, 10 Vrms max up to
35 MHz
• Scope vert in: DC to 500 kHz or 50 Hz to 500 kHz AC
mode (±3 d8)
• Sinad in: 0.5 to 10 Vrms in at 1 kHz
1-5
