Motorola Radius CM200

2-20 MAINTENANCE
10.0 Test Equipment
Table 2-6 lists test equipment required to service the radio and other two-way radios
.
Table 2-6 Recommended Test Equipment
Motorola Part No. Description Characteristics Application
R2000, R2600
R2400, or R2001
with trunking
option for Pri-
vacy Plus™ and
Smartnet Sys-
tems™
†
Service Monitor This monitor will
substitute for items
listed below with an
asterisk *
Frequency/deviation meter and sig-
nal generator for wide-range trouble-
shooting and alignment
*R1049 Digital Multimeter Two meters recommended for AC/
DC voltage and current measure-
ments
*S1100 Audio Oscillator 67 to 200Hz tones Used with service monitor for injec-
tion of PL tones
*S1053,
*SKN6009,
*SKN6001
AC Voltmeter,
Power Cable
for meter,
Test leads for meter
• 1 mV to 300 V
• 10 MΩ input imped-
ance
Audio voltage measurements
R1053 Dual-trace Oscillo-
scope
20 MHz bandwidth,
5 mV/cm - 20 V/cm
Waveform measurements
R1443A Broadband Watt-
meter
Transmitter power output measure-
ments
S1339 RF Millivolt Meter 100 µV to 3 VRF, 10
kHz to 1.2 GHz
RF level measurements
*R1013 SINAD Meter Receiver sensitivity measurements
S1348 (prog) DC Power Supply 0-20 Vdc, 0-20 Amps Bench supply for 13.8Vdc
