7-8 MODEL CHART AND TEST SPECIFICATION
2.5 Specifications
General
Specification VHF1 VHF2 UHF2 UHF3
Frequency Range: 136-162 MHz 146-174 MHz 438-470 MHz 465-495 MHz
Frequency Stability
(-30°C to +60°C, 25°C Ref.)
±2.5 PPM
Channel Capacity: CM300 - 32 CM200 - 4
CM300 - 32
PM400 - 64
PM400 -64
Channel Spacing: 12.5/25 kHz
Power Supply: 13.6 Vdc (10.88 Vdc - 16.32 Vdc) negative Vehicle ground
Dimensions (L x W x H) 4.65” X 6.67” X 1.73”
(118mm X 169.5mm X 44mm)
Weight 2.25 lbs (1.01 kg)
FCC Description ABZ99FT3049 ABZ99FT3046 ABZ99FT4048 ABZ99FT4049
Operating Temperature -30 to 60° C (Display only -20°C to 60°C)
Storage Temperature -40 to 85° C
Thermal Shock -40 to 80° C
High Humidity 95% RH @ 50° C for 8 hrs
ESD 15KV air discharge
Packing Test Impact Test
