Motorola RFS4010 Series User Manual

Hardware Setup
11
4 Hardware Setup
4.1 Cabling Information
The RFS4010 RF Switch has five RJ-45 Gigabit Ethernet ports, one Gigabit SFP (fiber) port, one USB
port, one Console connector and one ExpressCard slot. The above diagram shows each of those ports
and the cables or devices attached to them. The sections that follow describe detailed connection
and cabling information for each port. For software configuration, please see the RFS Series Wireless
LAN Switches Wi-NG System Reference Guide available from the Motorola website.
Console
LAN/PoE+ enabled gigabit ethernet
ports 1,2,3,4,5
USBUPLINK/
WAN
ExpressCard Slot
Gigabit Ethernet
RJ-45 connectors
with per-port LEDs
and PoE+
UPLINK Console connector
USB
port
ExpressCard Slot
