Motorola RFS4010 Series - RFS4010 RF Switch Console Port Setup

Hardware Setup
17
4.5 RFS4010 RF Switch Console Port Setup
To add the RFS4010 RF Switch to the network and prepare it for initial configuration:
1. Using the supplied console cable (pictured below), connect the RFS4010 RF Switch serial port to
an RS-232 (DB-9) serial port on a separate computer (the “configuration computer”).
CONSOLE
Console Port
