RS-232 Interface 7-5
RS-232 Parameter Defaults
Table 7-1 lists the defaults for RS-232 host parameters. If any option needs to be changed, scan the appropriate bar code(s) provided
in the Parameter Descriptions section beginning on page 7-6.
See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 7-1. RS-232 Host Default Table
Parameter Default Page Number
RS-232 Host Parameters
RS-232 Host Types Standard 7-8
Baud Rate 9600 7-9
Parity Type None 7-10
Stop Bit Select 1 Stop Bit 7-11
Data Bits (ASCII Format) 8-Bit 7-11
Check Receive Errors Enable 7-12
Hardware Handshaking None 7-13
Software Handshaking None 7-14
Host Serial Response Time-out 2 sec 7-16
RTS Line State Low RTS 7-17
Beep on <BEL> Disable 7-17
Intercharacter Delay 0 msec 7-18
Nixdorf Beep/LED Options Normal Operation 7-19
Ignore Unknown Characters Send Bar Code 7-19
