Motorola SYMBOL LS7708

Other manuals for Motorola SYMBOL LS7708

Quick Reference Guide36 pages

Questions and Answers

T
Thomas ColemanJul 29, 2025
What to do if Motorola Barcode Reader can't read barcodes?
- S
  Sarah GonzalezJul 29, 2025
  If your Motorola Barcode Reader displays scan lines but fails to read barcodes, it could be due to several reasons: * The scanner may not be programmed to read that specific barcode type. Ensure it's configured correctly. * The barcode itself might be damaged; try scanning other barcodes of the same type. * The barcode might be too far away; try moving it closer to the scanner. * The host system might have disabled scanning or changed settings. Consult with the technical staff responsible for scanning.
B
Bradley WoodsAug 4, 2025
Why is Motorola SYMBOL LS7708 displaying scanned data incorrectly?
- J
  Joseph PetersenAug 4, 2025
  If your Motorola Barcode Reader displays scanned data incorrectly on the host system, ensure the proper host is selected. If you are using RS-232, verify that the scanner’s communication parameters match the host’s settings. For keyboard wedge, make sure the scanner is programmed with the correct country code and that the CAPS LOCK key is off. Also, confirm that editing options like UPCE-to-UPCA Conversion are correctly programmed.
J
Joshua ClarkAug 9, 2025
Why Motorola Barcode Reader decodes, but does not transmit the barcode to the host?
- D
  David HaynesAug 9, 2025
  If your Motorola Barcode Reader decodes a barcode but doesn't transmit it to the host, the scanner may not be programmed for the correct host type. Scan the appropriate host type barcode to resolve this.
S
Samantha OwensAug 13, 2025
How to fix a Motorola SYMBOL LS7708 Barcode Reader that does not power on?
- E
  Eric James PhDAug 13, 2025
  If your handheld Motorola Barcode Reader doesn't power on, ensure that an external power supply is connected directly to the scanner and not to the host cable.
B
bradley52Aug 18, 2025
Why doesn't the omni-line scan pattern display on my Motorola SYMBOL LS7708 Barcode Reader?
- J
  Janet VelasquezAug 18, 2025
  If the omni-line scan pattern does not appear when installing the host cable on your Motorola Barcode Reader, ensure the host has power and is turned on. If the scanner uses a separate power supply, make sure it's connected to a working AC outlet. Also, check for loose connections in the interface cable.
K
kirbyhenryAug 25, 2025
What to do if Motorola SYMBOL LS7708 Barcode Reader doesn't produce the omni-directional scan pattern?
- J
  Jordan FerrellAug 25, 2025
  If the green and red Power LEDs are on, but the Motorola Barcode Reader does not produce the omni-directional scan pattern, the scanner may have entered Low Power “Motor Sleep” Mode. Press the Volume Control & Wakeup button to awaken the scanner.
