Symbol LS7708 Product Reference Guide5-20

Caps Lock Override

When enabled, on AT or AT Notebook hosts, the keyboard ignores the state of the Caps Lock key. Therefore, an ‘A’ in the bar code is

sent as an ‘A’ regardless of the state of the keyboard’s Caps Lock key.

Enable Caps Lock Override

*Disable Caps Lock Override

If both Caps Lock On and Caps Lock Override are enabled, Caps Lock Override takes precedence.

Note

Default Chapter5
