Symbol LS7708 Product Reference Guide13-78

Codabar (NW - 7)

Enable/Disable Codabar

To enable or disable Codabar, scan the appropriate bar code below.

Enable Codabar

*Disable Codabar

When a large gap bar code is encountered, see Symbology - Intercharacter Gap on page 13-94.

Note
