Symbol LS7708 Product Reference Guide7-14

USB Country Keyboard Types (continued)

Portuguese-Brazilian, Windows

USB Keystroke Delay

This parameter sets the delay, in milliseconds, between emulated keystrokes. Scan one of the following bar codes to increase the

delay when hosts require a slower transmission of data.

No Delay

Default Chapter5
