Symbol LS7708 Product Reference Guide13-48

Code 39 Check Digit Verification

When this feature is enabled, the scanner checks the integrity of all Code 39 symbols to verify that the data complies with specified

check digit algorithm. Only those Code 39 symbols which include a modulo 43 check digit are decoded when this feature is enabled.

This feature should only be enabled if the code 39 symbols contain a module 43 check digit.

Enable Code 39 Check Digit

*Disable Code 39 Check Digit
