Beep After Good Decode

Scan a bar code below to select whether or not the scanner beeps after a good decode. If Do Not Beep After Good Decode is

selected, the beeper still operates during parameter menu scanning and indicates error conditions.

*Beep After Good Decode

(Enable)

Do Not Beep After Good Decode

(Disable)
