Motorola SYMBOL LS7708 - RS-232 Auxiliary Port Default Parameters

RS-232 Auxiliary Port 10-5
RS-232 Auxiliary Port Default Parameters
Table 10-1 lists the defaults for RS-232 auxiliary parameters. To change any option, scan the appropriate bar code(s) beginning in
RS-232 Auxiliary Port Parameters on page 10-6.
See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 10-1. RS-232 Auxiliary Port Default Parameters
Parameter Default Page Number
Baud Rate 9600 10-6
Parity None 10-9
Check Receive Errors Enable 10-11
Hardware Handshaking None 10-12
Software Handshaking None 10-15
Serial Response Time-out 2 Sec 10-17
RTS Line State Low RTS 10-20
Stop Bit Select 1 10-21
Data Bits 8-Bit 10-22
Note
