Wand Emulatio
n Interfac
e
10-7
Leading Margin (Quiet Zone)
Scan a bar code below to select a leading margin dura
tion. A leadi
ng margin is the time that precedes
the first bar of the scan
, (in
milliseconds). The minimum allowed value is 80 msec an
d th
e maximum is 250 msec. This param
eter accommodates older wand
decoders whic
h cannot handle short leading
margins.
250 msec is the maximum value that this parameter can attain
, however
, 200 msec is sufficie
nt.
*
80 msec
140 msec
200 msec
180
182
