USB Interface
8-7
USB Country Keyboard
T
ypes (Country Codes)
Scan the bar code correspon
ding to the keyboard type. This setti
ng applies only to the USB HID Key
board Emulat
ion device
.
When changing USB country keyb
oard types the scanner automat
ically resets. The scanner issues the sta
ndard startup
beep sequences.
*
North American Standard USB Keyboard
German Windows
French Windows
French Canadian Windows 95/98
French Canadian Wi
ndows 2000/XP
Spanish Windows
150
152
