Mountz PTT-2000 - Page 12

Angle Setup
Angle Threshold: 2 deg
Angle Polarity: Normal
Angle Encoder: 360
Main
1. Use the Scroll Left or Right key to toggle between Angle Threshold and
Angle Polarity.
2. Use the Scroll Up or Down key to toggle through the degree values (0.25-5)
for Angle Threshold. It move at increments of 0.25
3. Use the Scroll Up or Down key to toggle Angle Polarity options: Normal or
Reverse
4. Press Enter key once setting is complete.
5. Press Main button to return to main display screen.
Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733
www.etorque.com
Page 12
Tolerance
Auto Clear
Angle Setup
T+A Threshold
First Peak
Spindle Audit
This allows an operator to set up an initial torque and follow up with a rotation to a specified angle and display the
final torque.
Torque + Angle
Torque+Angle Thresh
Angle: 2.00 deg
Torque: 50.000 lbf.in
Allow Ratchet: No
Main
1. Press the "Menu" Button.
2. Use the Scroll Down key and select Setup by highlighting and pressing Enter.
3. Use the Scroll Up or Down key to toggle through the Setup options.
4. Press Enter key to select a setup setting for Torque + Angle.
Filter
Units
Mode
Setup
Selecting Torque + Angle
1. Press the Right or Left key to toggle between the three settings: Angle, Torque
Allow Ratchet
2. Use the Scroll Up or Down key to set Angle (increments of 0.25)
3. Use the Scroll Up or Down key to set Torque (increments of 0.5)
4. Use the Scroll Up or Down key to set “Yes” or “No” for allowing ratchet*.
5. Press Enter key once setting is complete.
6. Press Main button to return to main display screen.
* Note - “Yes” allows for ratcheting the wrench back without accumulating
angle.
