Movo SUTTON - Throttle and Adjustment Controls

BROME
User Guide
Horn :
Press down the button to sound buzzer.
Throttle :
•
Pull the right throttle to move scooter forward. /Pull the left throttle to move
scooter backward. This can be reversed if required by local dealer. (Figure 10)
• These are also your accelerator. The further you depress them, the faster
you go. (Subject to the position of speed control)
• Releasing both left /right throttles automatically operates the brakes to slow
down and stop. Brake light will be activated and have steady red light on for 5
seconds. (Figure 10)
Tiller angle adjustment :
• Pull the tiller adjustment downwards to adjust tiller’s angle and release to lock at a
desired comfortable position. (Figure 12)
Seat Swivel Adjustment :
•
Pull the swivel
lever upwards to
rotate seat left
and right.
(Figure 13)
Seat fore-aft Adjustment :
•
Set at a comfortable position by
lifting lever forward to adjust the
seat. (Figure 14)
Armrest angle, height, and width adjustment :
•
Angle : rotate the screw as picture to adjust the most comfortable armrest angle. (Figure
15)
•
Width : Loosen the thumbscrews as picture to adjust the width, tighten again to
lock at a desired position. (Figure 16)
•
Pull the armrest up when getting on or off the scooter.
13
Do not pull both right and left throttle at the same time, you might not able to control the
scooter. Always ensure the
Figure 14
When driving the scooter, place the seat in the most forward position to prevent it from tipping
over. Do not hang heavy objects from the armrests.
