Movo SUTTON - Free-Wheeling and Disassembly; Free-Wheeling (N-D Lever); Tie-Down Hooks and Scooter Disassembly

BROME
User Guide
1. FREE-WHEELING (N-D LEVER)
• When lever is in Neutral (N) position, scooter can be moved manually without power. (Figure
17-2)
•
When lever is in Drive (D) position, scooter can be driven. Normal position is D. (Figure
17-1)
2. TIE-DOWN HOOKS
•
To ensure safety during the transportation.
There are four fixed hooks for fixing scooter
on other vehicles.
•
Make sure the scooter’s N-D lever is in D
position when transporting.
•
Do not sit on the scooter during transportation.
3. DISASSEMBLING YOUR SCOOTER
•
Remove the seat by lifting the lever to remove the seat upwards. (Figure 19)
•
For the rear compartment cover, Open the compartment cover upwards (Figure 20)
•
Lift the front basket upward. (Figure 21)
14
Figure 15
Figure 16
Freewheel operation is only recommended on flat
surfaces. Never leave your scooter on gradient with its
motors disengaged.
When adjusting N-D lever, do not sit on the scooter. It’s
not able to drive the scooter when the lever is in Neutral.
You must turn off the scooter first and switch to D lever,
then turn on and drive scooter.
Figure 17
Do not turn on the scooter when disassemble/assemble the scooter, and make sure the scooter
is in D position. Do not modify or change the scooter with non-authorized parts or
accessories.
