Movo SUTTON - Disassembling Batteries

BROME
User Guide
4. DISASSEMBLING BATTERIES
Release the battery velcro straps and disconnect the battery connectors to remove the
batteries.
15
Figure 19
Figure 20
Figure 21
Batteries are heavy, be careful when removing the batteries.
Do not connect battery terminal [+] [-] with any metals to avoid danger. Connect the red
terminal to red, blue terminal to blue.
When replacing the batteries remove the screws and connectors in sequence and tighten each
component back.
Maintenance & repair must only be carried out by a competent engineer or authorized dealer.
