Movo SUTTON - Technical Specifications

BROME
User Guide
TECHNICAL SPECIFICATION
Overall Length
1400 mm / 55.1"
Overall Width
680 mm / 26.8"
Overall Height
1325 mm / 52.2"
Front Wheels
330 mm / 13"
Rear Wheels
330 mm / 13"
Weight W/ Batteries
142 kg / 313 Ibs
Max. Speed
15 kmph / 9.3 mph
Weight Capacity
160 kg / 352.7 Ibs
Ground Clearance
90 mm / 3.5"
Grade Climbable
10 degree
Curb Climbable
100 mm / 3.9"
Turning Radius
1660 mm / 65.4"
Suspension
Front & Rear
Brake
Hand Brake & Electro-Mechanical
Seat Type
Swivel Captain Seat With Seat Sliding
Mechanism & Back Angle Adjustment
Seat Width
515 mm / 20.3"
Motor Size
850W, 5000 r.p.m.
Battery Size
(2) 12V. 75Ah
Weight of Battery
50 kg / 110 lbs
Travel Range
50 km / 31 Miles
Battery Charger
8A Off Board
23
