Recommended range of storage,
Temperature : -30
o
c ~ +50
o
c, Humidity : 25% ~ 85%
Follow these easy steps to replace the tire :
1. Turn off the scooter and remove the
key. Make sure the lever is in D
position before you lift the scooter.
2. Use an ratchet and socket to remove
the drive wheel screw from the centre
hub of the wheel. Pull the wheel off of
the axle.
3. Separate the tire from the rim.
4. Remove the old tire and replace it with
a new tire. 5.Slide the wheel back onto
the shaft.
6.Install the drive wheel nut into the centre hub and verify the key is lined up with
axle and wheel,then tighten to secure it in place. (Torque 300±30kgf-cm)
All maintenance and repair of scooter should be done by an
authorized dealer.
