PCI Express Boards Software Installation
4. When you see the screen below, select “Esc” to exit and reboot your computer.
MOXA Smartio/Industio Family Installation Utility (Ver 1.11)
Smartio/Industio Family Basic Configuration
PgDn: getty Setting
Enter: Confirm Input Value
Esc: Exit
Tab: Change Item
5. After rebooting the computer, type “moxaadm”; when you see MAIN MENU, select Basic
Configuration.
MAIN MENU
Basic Configuration
Advanced Configuration
Interface Configuration
Port Monitoring
Terminal Emulation
Driver Removal
Exit
6. You will see the following screen. Press Enter to select the MOXA Multiport Serial Board you installed by
port and by model. For example, if you installed the CP-104EL, select 4 ports and then CP-104EL.
MOXA Smartio/Industio Family Installation Utility (Ver 1.11)
Smartio/Industio Family Basic Configuration
PgDn: getty Setting
Enter: Confirm Input Value
Esc: Exit
Tab: Change Item
7. The board’s basic information, such as I/O address, Bus No., and Device No., will be shown. The SCO
system will assign the resources automatically to the PCI Express board you selected.
8. Next, press “Esc” to exit and reboot your computer.
Steps 9 and 10 are only for the CP
-132EL Series and CP-114EL Series
9. After rebooting, type “moxaadm”. When you see MAIN MENU, select Interface Configuration to set
your Resister and Interface. For example, if you want to set one of the CP-114EL ports as RS-422 and
120Ω, you have to select RS-422 and 120Ω.
10. Save your Interface Configuration and then reboot the computer again.
11. Note that whenever you change a MAIN MENU item, you need to reboot your computer.
To Next Page
