Moxa Technologies CP-134N Series User Manual

PCI Express Boards Programming Guide
6-6
Moxa Board PCI Device ID List
Model Ports Bus Chip Max Baud Vendor ID Device ID
CP-102U 2 UPCI MU860 921.6k 0x1393 0x1022
CP-102UL 2 UPCI MU860 921.6k 0x1393 0x1021
CP-132UL 2 UPCI MU860 921.6k 0x1393 0x1321
CP-132UL-I 2 UPCI MU860 921.6k 0x1393 0x1321
CP-102E 2 PCIe MUE250 921.6k 0x1393 0x1024
CP-102EL
2
PCIe
MUE250
921.6k
0x1393
0x1025
CP-132EL 2 PCIe MUE250 921.6k 0x1393 0x1322
CP-132EL-I 2 PCIe MUE250 921.6k 0x1393 0x1322
CP-104UL 4 UPCI MU860 921.6k 0x1393 0x1041
CP-104JU 4 UPCI MU860 921.6k 0x1393 0x1042
CP-114UL 4 UPCI MU860 921.6k 0x1393 0x1143
CP-114UL-I
4
UPCI
MU860
921.6k
0x1393
0x1143
CP-134U 4 UPCI MU860 921.6k 0x1393 0x1340
CP-134U-I 4 UPCI MU860 921.6k 0x1393 0x1340
CP-104EL-A 4 PCIe MUE450 921.6k 0x1393 0x1045
CP-114EL
4
PCIe
MUE450
921.6k
0x1393
0x1144
CP-114EL-I 4 PCIe MUE450 921.6k 0x1393 0x1144
CP-134EL-A 4 PCIe MUE450 921.6k 0x1393 0x1342
CB-114 4 PC/104-Plus MU860 921.6k 0x1393 0x1142
CB-134I 4 PC/104-Plus MU860 921.6k 0x1393 0x1341
CP-118U 8 UPCI MU860 921.6k 0x1393 0x1180
CP-118U-I
8
UPCI
MU860
921.6k
0x1393
0x1180
CP-138U 8 UPCI MU860 921.6k 0x1393 0x1380
CP-138U-I 8 UPCI MU860 921.6k 0x1393 0x1380
CP-168U 8 UPCI MU860 921.6k 0x1393 0x1681
CP-116E-A(A)
8
PCIe
MUE850
921.6k
0x1393
0x1160
CP-116E-A(B) 8 PCIe MUE850 921.6k 0x1393 0x1161
CP-118EL-A 8 PCIe MUE850 921.6k 0x1393 0x1182
CP-118E-A-I
8
PCIe
MUE850
921.6k
0x1393
0x1183
CP-138E-A-I 8 PCIe MUE850 921.6k 0x1393 0x1381
CP-168EL-A 8 PCIe MUE850 921.6k 0x1393 0x1683
CB-108 8 PC/104-Plus MU860 921.6k 0x1393 0x1080
UART Datasheet
Moxa’s chips are compatible with the following chips. For more details about UART register description,
please refer to the links below.
UART
Port
Datasheet
MU-860 2-8 TL16C550C
MUE-250 2 PI7C9X7952
MUE-450 4 PI7C9X7954
MUE-850
8
PI7C9X7958

Moxa Technologies CP-134N Series Specifications

General

Brand	Moxa Technologies
Model	CP-134N Series
Category	PCI Card
Language	English
