PCI Express Boards Programming Guide
6-2
Relative Product List
Resource Requirement for Moxa Board
IRQ * 1
I/O :
UART register : 64 bytes ( 8 bytes / port * 8port ) for MU860
4096 bytes ( 512 bytes / port * 8port ) for MUE250/450/850
IRQ Vector register : 16 bytes ( only 1 byte used )
PCI Configuration for Moxa Board
A. MOXA Vendor ID = 0x1393
B. Device ID = (Please see Moxa Board PCI Device ID List section)
C. Hardware resource on Device Configuration Register of PCI configuration space:
Resource Name Chip Address Offset Size
IRQ All 0x3C
IRQ Vector Address MU860 0x1C BAR3 16 bytes
UART register
(I/O Base Address)
MU860 0x18 BAR2 64 bytes
UART register
(Memory Base Address)
MUE250, MUE450, MUE850 0x14 BAR1 4096 bytes
Vector Base Address
MUE250, MUE450, MUE850
0x18
BAR2
16 bytes
Byte Offset 0-7 8-15 16-23 24-31
00h Vendor ID Device ID
04h Command Status
08h …
0Ch …
10h
BAR0
14h BAR1
18h BAR2
1Ch BAR3
… …
3Ch Interrupt Line Interrupt Pin Reserved
NOTE
For MUE250, MUE450, and MUE850 Chips Only:
Memory mode is recommended for these chips to access
UART. To use memory mode,
the driver has to access the memory base address, which is located at BAR1.
