PCI Express Boards Product Specifications
CP-138E-A-I Specifications
Hardware
Connector Female DB 78
Comm. Controller 16C550C Compatible
Interface
Bus Interface PCI-Express x 1
Number of Ports 8
Signal
RS-422 TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND
4-wire RS-485 TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND
2-wire RS-422 Data+(B), Data-(A), GND
Performance
Configuration
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2
Parity None, Even, Odd, Space, Mark
Flow Control RTS/CTS, XON/XOFF
Power and Environment
Power Requirement 2356 mA (3.3V)
Operating Temperature 0 to 55°C (32 to 132°F)
Storage Temperature -20 to 85°C (-4 to 185°F)
ESD Protection Embedded 15 kV ESD Protection
Surge Protection 4 kV
Standards and Certifications EN55032, EN55024, EN61000-3-2, EN61000-3-3, IEC 61000-4-2, IEC
61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-
4-8,
IEC 61000-4-11 FCC Part 15 Class B
Warranty 5 years
