Moxa Technologies EDS-405A Series Quick Installation Guide

- 17 -
Power
Input Voltage • EDS-405A/408A Series:
12/24/48 VDC, redundant inputs
• EDS-408A-3S-SC-48:
±24/±48 VDC (-60 to -19 VDC or 19 to 60
VDC), redundant inputs (The mixing of power
polarity system is prohibited.)
Input Current
• EDS-405A Series:
0.594 A/0.286 A/0.154 A @ 12/24/48 V
• EDS-408A Series (copper and 2 fiber models):
0.61 A/0.3 A/0.16 A @ 12/24/48 V
• EDS-408A Series (3 fiber m odels):
0.73 A/0.35 A/0.18 A @ 12/24/48 V
Inrush current
• EDS-405A Series:
Max. 2.08 A @ 24 VDC (0.1 - 1ms)
• EDS-408A 3 Fiber Model:
Max. 15.96 A @ 24 VDC (0.1 - 1ms)
• EDS-408A Copper and 2Fiber Model:
Max. 1.90 A @ 24 VDC (0.1 - 1ms)
Conne ction
One rem ovable 6-pin terminal block
Overload Current
Protection
Present
Reverse Polarity
Protection
Present
Physical Characteristics
Housing
Metal, IP30 protected
Dim ensions
53.6 × 135 × 105 mm
Weight
0.65 kg (EDS-405A), 0.89 kg (EDS-408A)
Installation
DIN-rail, Wall Mounting (optional kit)
Environmental Limits
Operating
Tem perature
-10 to 60°C (14 to 140°F);
-40 to 75°C (-40 to 167°F ) for -T models
Storage
Tem perature
-40 to 85°C (-40 to 185°F)
Am bient Relative
Hum idity
5% to 95% (non-condensing)
Regulatory Approvals
Safety
• EDS-405A/408A: UL 60950-1, UL 508,
EN 60950-1
• EDS-408A-3S-SC-48: UL508
Hazardous Location
UL/cUL Class I, Division 2, Groups A, B, C and D,
ATEX Zone 2, IECEx
EDS-405A/EDS-408A Series (copper and 2 fiber
m odels):
ANSI/ISA-12.12.01-2015
CSA C22.2 No. 213-17,
EN IEC 60079-0:2018
EN IEC 60079-15: 2019
EN 60079-28:2015 (for EDS-408A-MM/SS only)
EDS-408A(-T), EDS-408A-MM/SS(-T):
IEC 60079-0, 7th Edition (2017-12) + Corr. 1
(2020-01) + I-SH 01 (2019-04) + I-SH 02
(2019-06)
IEC 60079-7, Edition 5.1 (2017-08)
IEC 60079-15, 5th Edition (2017-12)
