Moxa Managed Ethernet Switch (UI_2.0_FW_5.x) User Manual
72
Priority Mapping (Type 2)
CoS Value and Priority Queues
Setting
Description
Factory Default
0 to 7 Maps different CoS values to 8 different egress queues.
CoS 0: 0
CoS 1: 1
CoS 2: 2
CoS 3: 3
CoS 4: 4
CoS 5: 5
CoS 6: 6
CoS 7: 7
DSCP Mapping
