Moxa Managed Ethernet Switch (UI_2.0_FW_5.x) User Manual
Port Access Control Table
The port status will be indicated as authorized or unauthorized.
Broadcast Storm Protection
Broadcast Storm Protection is only supported by the EDS-G508E, EDS-G512E-4GSFP, EDS-G516E-4GSFP,
IKS-6726A/6728A/ 6728A-8PoE, EDS-G512E-8PoE, EDS-518E, EDS-528E, and EDS-P506E Series.
Broadcast Storm Protection
Broadcast storm protection is not activated.
Checked
Checked
Broadcast storm protection is activated. In this case, you may
check either one or both of Include Multicast Packet and
Include Unknown Unicast Packet.
Include Multicast Packet
When checked, the switch will discard Multicast packets if the Multicast traf f ic is over the Multicast packet
limit.
NOTE
For IKS-6726A/6728A/6728A-8PoE, EDS-518E, EDS-528E, and EDS-P506E Series, only ‘Known Multicast
Packet’ can be discarded if the ‘Include Multicast Packet’ feature is checked and traff ic exceeds the limit.
