EDS-408A/405A Series User’s Manual EDS Configurator GUI
4-2
Starting EDS Configurator
To start EDS Configurator, locate and then run the executable file edscfgui.exe.
NOTE
You may download the EDS Configurator software from Moxa’s website at www.moxa.com.
For example, if the file was placed on the Windows desktop, it should appear as follows. Double
click the icon to run the program.
The MOXA EtherDevice Switch Configurator window will open, as shown.
Broadcast Search
Use the Broadcast Search utility to search the LAN for all MOXA EtherDevice Switches that are
connected to the LAN. Note that since the search is done by MAC address, Broadcast Search will
not be able to locate MOXA EtherDevice Servers connected outside the PC host’s LAN. Start by
clicking the Broadcast Search icon
, or by selecting Broadcast Search from the List Server
menu.
The Broadcast Search window will open, displaying a list of all switches located on the network,
as well as the progress of the search.
