“Turbo Ring V2” DIP Switch Settings
ON: Enables the
default “Ring
Coupling
(backup)” port
when DIP switch
3 is already
ON: Enables this
EDS as the Ring
Master.
ON: Enables the
default “Ring
Coupling” port.
ON: Activates
DIP switch 1, 2,
and 3 to
configure “Turbo
Ring V2”
settings.
default “Ring
Coupling
(primary)” port
when DIP switch
3 is already
will not be the
Ring Master.
OFF: Do not use
this EDS as a ring
You must enable the Turbo Ring function first
DIP switch to activate the Master and Coupler functions.
If you do not enable any of the EDS
switches to be
the Ring Master, the Turbo Ring protocol will automatically
choose the EDS
-G500E series with the smallest MAC address
range to be the Ring Master. If you accidentally enable more than
one EDS
-G500E series to be the Ring Master, these EDS-G500
negotiate to determine which one will be
the Ring Master.
LED Indicators
The front panel of the Moxa EDS-G500E series contains several LED
indicators. The function of each LED is described in the following table:
The system passed the self-diagnosis test
on boot-up and is ready to run.
Blinking
1. The switch is under reset progress (1
time/s).
2. Detect ABC-02-USB connect to the
The system failed self-diagnosis on
boot-up.
• RAM Test Fail / System Info. Read Fail
/ Switch Initial Fail / PTP PHY Error.
(+ Green MSTR lit on : HW FAIL)
• FW Checksum Fail / Uncompress Fail.
(+ Green Coupler lit on: SW FAIL)
1. The signal contact is open.
2. ABC Loading/Saving Fail.
3.
The port being disabled because of the
ingress multicast and broadcast
packets exceed the ingress rate limit.
4. Incorrect loop connection in a single
