SFP port’s 100 Mbps link is active.
Data is being transmitted at 100 Mbps.
SFP port’s 100 Mbps link is inactive.
SFP port’s 1000 Mbps link is active.
Data is being transmitted at 1000 Mbps.
SFP port’s 1000 Mbps link is inactive.
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseX
Protocols IGMPv1/v2/v3, GMRP, GVRP, SNMPv1/v2c/v3,
DHCP Server/Client, DHCP Option 66/67/82, BootP,
TFTP, SNTP, SMTP, RARP, RMON, HTTP, HTTPS,
Telnet, SSH, Syslog, EtherNet/IP, PROFINET,
Modbus/TCP, SNMP Inform, LLDP, IEEE 1588 PTP
V2, IPv6, NTP Server/Client
MIB-II, Ethernet-Like MIB, P-BRIDGE MIB,
Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB
IEEE 802.3x flow control, back pressure flow control
8 (EDS-G508E/EDS-G512E-4GSFP) or 12
(EDS-G516E-4GSFP) 10/100/1000BaseT(X)
4-port 100/1000BaseSFP slot
(EDS-G512E-4GSFP/EDS-G516-4GSFP only)
USB Ports USB console port (type B connector)
USB storage port (type A connector)
PWR1, PWR2, FAULT, STATE, 10/100M, 100/1000M,
MSTR/HEAD, CPLR/TAIL
1 relay output with current carrying capacity of 1 A
@ 24 VDC
1 input with the same ground, but electrically
isolated from the electronics.
+13 to +30V for state “1”
-30 to +3V for state “0”
12/24/48/-48 VDC, redundant dual inputs
Input Current EDS-G516E: 0.46 A @ 24 VDC
EDS-G512E: 0.4 A @ 24 VDC
EDS-G508E: 0.33 A @ 24 VDC
2 removable 4-contact terminal blocks
Overload Current
Protection
