Moxa Technologies EtherDevice EDS-G500E Series User Manual

- 14 -
LED
Color
Status
Description
5. Invalid Ring port connection.
PWR1 Amber
On
Power is being supplied to the main
module’s power input PWR1.
Off
Power is not being supplied to the main
module’s power input PWR1.
PWR2 Amber
On
Power is being supplied to the main
module’s power input PWR2.
Off
Power is not being supplied to the main
module’s power input PWR2.
MSTR/
HEAD
Green
On
1.
The switch is set as the Master of the
Turbo Ring, or as the Head of the
Turbo Chain.
2. POST H.W. Fail (+Stat on and Fault
blinking).
Blinking
1. The switch has become the Ring
Master of the Turbo Ring.
2.
The Head of the Turbo Chain, after the
Turbo Ring or the Turbo Chain is
down.
3. The switch is set as Turbo Chain’s
Member and the corresponding chain
port is down.
Off
1. The switch is not the Master of this
Turbo Ring.
2. This switch is set as a Member of the
Turbo Chain.
CPLR/
TAIL
Green
On
1. The switch’s coupling function is
enabled to form a back-up path.
2. When it’s set as the Tail of the Turbo
Chain.
3. POST S.W. Fail (+Stat on and Fault
blinking)
Blinking
1. Turbo Chain is down.
2. The switch is set as Turbo Chain’s
Member and the corresponding chain
port is down.
Off
1. This switch has disabled the coupling
function.
2. This switch is set as a Member of the
Turbo Chain.
FAULT +
MSTR/HEAD
+ CPLR/TAIL
Rotate
Blinking
Sequentially
ABC-02-USB is importing/exporting files.
STATE +
FAULT +
MSTR/HEAD
+ CPLR/TAIL
Blinking
Switch is being discovered/located by
MXview (2 times/s).
10M/
100M
(TP)
Amber
On
TP port’s 10 or 100 Mbps link is active.
Blinking
Data is being transmitted at 10 or 100
Mbps.
Off
TP port’s 10/100 Mbps link is inactive.
1000M
(TP)
Green
On
TP port’s 1000 Mbps link is active.
Blinking
Data is being transmitted at 1000 Mbps.
Off
TP port’s 1000 Mbps link is inactive.
