Moxa Technologies IMC-21GA User Manual

- 11 -
DIP Switch
The following are DIP switch selectable:
Fiber port’s connection speed (FX Speed),
Energy Efficient Ethernet (EEE),
Link Fault Pass Through (LFP)
Fiber Optics
Multi mode
(IMC-21GA-SX-SC)
Single mode
(IMC-21GA-LX-SC)
Distance, km
0.5
10
Wavelength, nm
850
1310
Min. Tx Output, dBm
-10
-9
Max. Tx Output, dBm
-3
-3
Sensitivity, dBm
-20
-21
Power Requirements
Input Voltage
12 to 48 VDC (10 to 60 VDC)
Input Current
284.7 mA @ 12 VDC; 156.0 mA @ 24 VDC
Connection
Removable 4-contact screw-on terminal block
Overload Current
Protection
1.5 A
Reverse Polarity
Protection
Present
Physical Characteristics
Housing
IP30 protect, metal case
Dimensions
30 × 115 × 70 mm (1.19 x 4.53 x 2.76 in)
Weight
170 g
Installation
DIN rail mounting
Environmental Limits
Operating
Temperature
Standard models: -10 to 60°C (14 to 140°F)
Wide temp. models: -40 to 75°C (-40 to 167°F)
Storage Temperature
-40 to 75°C (-40 to 167°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Regulatory Approvals
Safety
UL 60950-1
EMI
FCC Part 15, CISPR (EN 55022) class A
EMS EN 61000-4-2 (ESD) Level 3
EN 61000-4-3 (RS) Level 3
EN 61000-4-4 (EFT) Level 3
EN 61000-4-5 (Surge) Level 3
EN 61000-4-6 (CS) Level 3
Shock
IEC 60068-2-27
Free Fall
IEC 60068-2-32
Vibration
IEC 60068-2-6
Warranty
5 years
Federal Communications Commission Statement
FCC—This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
