NPort 5000 Series User Manual
112
Model Name
Firmware version supporting encrypted configuration files.
NPort 5600-8-DT Series
Firmware v2.4 and up with NPort Administration Suite v1.22 and up
NPort 5600-8-DTL Series
Firmware v1.3 and up with NPort Administration Suite v1.22 and up
NPort 5600 Series
Firmware v3.7 and up with NPort Administration Suite v1.22 and up
NPort 5000A/IA5000A Series
NPort 5100A Series
Firmware v1.3 and up (Support with both web console and NPort
Administration Suite v1.22 or above)
NPort 5200A Series
Firmware v1.3 and up (Support with both web console and NPort
Administration Suite v1.22 or above)
NPort 5x50AI-M12 Series
Firmware v1.2 and up (Support with both web console and NPort
Administration Suite v1.22 or above)
NPort IA5150A, NPort
IA5250A
Firmware v1.3 and up (Support with both web console and NPort
Administration Suite v1.22 or above)
NPort IA5450A
Firmware v1.4 and up (Support with both web console and NPort
Administration Suite v1.22 or above)
ATTENTION
1. You can simultaneously import the same configuration file into multiple NPort units of the same model.
To select multiple NPort units, hold down the Ctrl key when selecting an additional NPort, or hold
down the Shift key to select a block of NPort units.
2. If you have an encrypted configuration file, you will need to use the NPort Administration Suite V1.22
or above to import an encrypted configuration file. On the other hand, if your configuration file is non-
encrypted, it will also be accepted by the NPort Administration Suite V1.22 or above. (i.e. the NPort
Administration Suite will not ask you to key in the Import Password.
Monitor
Use the following method to start the Monitor function.
Broadcast Search > Monitor > Add Target
1. With Configuration selected under Function, use Broadcast Search to locate all NPorts on your LAN.
2. Next, click Monitor > Add Target and select your targets from the list, and then click OK.

Moxa Technologies NPort 5130A Specifications

General

Isolation	1.5 kV
Certification	CE, FCC
Serial interface type	RS-422, RS-485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, HTTP, SMTP, IGMP v1/2
Compatible operating systems	SCO Unix, OpenServer UnixWare v2.1, v7 Unix SVR 4.2 Unix QNX 4.25, QNX 6 Solaris 10 FreeBSD AIX 5.x HP-UX 11i Mac OS v10.3 Linux v2.4.x, v2.6.x
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Input voltage	12 - 48 V
Safety	UL, LVD

Weight and Dimensions

Weight	340 g
Dimensions (WxDxH)	52 x 80 x 22 mm
