NPort 5000 Series User Manual
124
3. Select the Grouping selected port(s) together checkbox.
4. On the COM Grouping page, you can set “Read” and “Write” permissions for every serial port. It is
necessary to set Signal Status in order to control the data transmission with specified control signals
(e.g., DTR/RTS). You can assign one serial port whose signals will be taken into account by the COM
Group.
5. Click OK, and confirm that the serial ports that were assigned. The COM Port column confirms that your
selected ports are labeled as part of a “Group.” You will be able to view the serial ports that were
assigned to and removed from the Group. Click Apply to apply the settings.
6. Finally, click Yes to confirm.

Moxa Technologies NPort 5250A Specifications

General

Certification	CE, FCC EN 55022 Class A, FCC Part 15 Subpart B Class A EN 55024 EN 61000-4-4 EN 61000-4-5
Serial interface type	RS-232/422/485
Serial ports quantity	1
Supported network protocols	ICMP, IPv4, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP V1, HTTP, SMTP, IGMP V1/2
Storage temperature (T-T)	-40 - 75 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, EN 60950-1

Weight and Dimensions

Weight	340 g
Dimensions (WxDxH)	77 x 111 x 26 mm
